Description
The Bosch IQsight DINION 7100i IR 4MP HDR X bullet camera series provides a strong balance of high detail, advanced low-light performance, HDR X imaging, long-range IR illumination, and mission-critical outdoor construction. This consolidated 4MP page includes NBE-7703-ALX and NBE-7703-ALXT, allowing customers to select either the 4.7-10mm wide-angle version or the 10.5-47mm telephoto version.
The NBE-7703-ALX is designed for wide-area 4MP surveillance with a 4.7-10mm motorized P-iris lens and a 103° to 49° horizontal field of view. It is well suited for entrances, yards, industrial sites, parking areas, perimeter approaches, and outdoor public spaces. The NBE-7703-ALXT uses a 10.5-47mm motorized telephoto lens with a 41.6° to 9.3° horizontal field of view for long-distance identification and targeted monitoring of gates, roadways, fence lines, and critical assets.
Both NBE-7703-ALX and NBE-7703-ALXT use a 1/1.8" CMOS sensor with 2688 x 1520 effective pixels and Starlight X technology. The 4MP HDR X platform delivers up to 141dB dynamic range and supports 25/30fps HDR X modes as well as up to 60fps non-HDR modes. This makes the NBE-7703 series a strong fit where users need more detail than 1080p while retaining excellent low-light visibility and smooth motion options.
The integrated smart IR system provides 850nm illumination as standard, with optional 940nm invisible IR and optional white light modules. The NBE-7703-ALX wide variant supports up to 80m / 262ft 850nm IR, while the NBE-7703-ALXT tele variant supports up to 140m / 459ft 850nm IR. Optional 940nm IR supports up to 60m / 197ft on wide variants and up to 100m / 328ft on tele variants.
IVA Pro Buildings and IVA Pro Perimeter are included for deep-learning-based object detection and advanced perimeter surveillance. The camera supports object in field, line crossing, enter / leave field, loitering, follow route, idle / removed object, counting, occupancy, crowd density estimation, condition change, similarity search, traffic tracking, people tracking, and ship tracking. Optional licenses add IVA Pro Traffic, Appearance, PPE, License Plate, Vehicle Make Model, Dangerous Good Signs, Visual Gun Detection, and Gunshot Detection.
Built for harsh outdoor environments, the NBE-7703-ALX and NBE-7703-ALXT include IP66 / IP67 / IP6K9K ingress protection, NEMA Type 4X protection, IK10 impact resistance, corrosion-resistant aluminum housing, electronic image stabilization, dual microSD recording, audio and alarm I/O, punch-down or RJ45 Ethernet, Secure Element / TPM cybersecurity, ONVIF interoperability, PoE and auxiliary power, and NDAA compliance.
Key Features:
• Bosch IQsight DINION 7100i IR 4MP HDR X outdoor bullet camera series
• Models: NBE-7703-ALX and NBE-7703-ALXT
• 4MP resolution, 2688 x 1520
• Starlight X low-light performance
• HDR X with up to 141dB dynamic range
• Up to 60fps sensor modes
• NBE-7703-ALX with 4.7-10mm wide lens
• NBE-7703-ALXT with 10.5-47mm telephoto lens
• 850nm smart IR standard
• Up to 80m IR on NBE-7703-ALX
• Up to 140m IR on NBE-7703-ALXT
• Optional 940nm invisible IR modules
• Optional white light modules
• IVA Pro Buildings and IVA Pro Perimeter included
• Advanced perimeter, traffic, people, and vehicle analytics
• H.265 / H.264 / M-JPEG compression
• Electronic image stabilization
• Dual microSD card slots up to 2TB
• Shielded RJ45 and punch-down connector
• Audio and alarm I/O
• IP66 / IP67 / IP6K9K, NEMA Type 4X, IK10
• NDAA compliant
Technical Specifications Summary:
Camera:
• Resolution: 4MP
• Effective Pixels: 2688 x 1520
• Sensor Type: 1/1.8" CMOS
• Pixel Size: 2.9μm
• Low-Light Technology: Starlight X
• Frame Rate: 1fps to 60fps
• HDR: HDR X, up to 141dB
• Color Sensitivity:
- NBE-7703-ALX: 0.009 lux
- NBE-7703-ALXT: 0.0078 lux
• Monochrome Sensitivity:
- NBE-7703-ALX: 0.0012 lux, 0 lux with IR
- NBE-7703-ALXT: 0.0013 lux, 0 lux with IR
Lens Options:
• NBE-7703-ALX: 4.7-10mm motorized P-iris lens
• NBE-7703-ALX Horizontal FOV: 103° to 49°
• NBE-7703-ALX Vertical FOV: 53° to 27°
• NBE-7703-ALXT: 10.5-47mm motorized P-iris lens
• NBE-7703-ALXT Horizontal FOV: 41.6° to 9.3°
• NBE-7703-ALXT Vertical FOV: 23.9° to 5.3°
Night Vision:
• IR Function: On / Off / Auto / Intelligent IR
• Default Illumination: 850nm
• Optional Illumination: 940nm invisible IR or white light
• 850nm IR Distance, NBE-7703-ALX: 80m / 262ft
• 850nm IR Distance, NBE-7703-ALXT: 140m / 459ft
• Optional 940nm IR Distance, NBE-7703-ALX: 60m / 197ft
• Optional 940nm IR Distance, NBE-7703-ALXT: 100m / 328ft
• Illumination Intensity: Manual / Intelligent
DORI Coverage:
NBE-7703-ALX / 4.7-10mm:
• Detection: 43m to 118m
• Observation: 17m to 47m
• Recognition: 9m to 24m
• Identification: 4m to 12m
NBE-7703-ALXT / 10.5-47mm:
• Detection: 140m to 683m
• Observation: 56m to 271m
• Recognition: 28m to 137m
• Identification: 14m to 68m
Model Variants:
• NBE-7703-ALX – 4MP HDR X DINION 7100i IR Bullet Camera, 4.7-10mm Lens, Wide IR
• NBE-7703-ALXT – 4MP HDR X DINION 7100i IR Bullet Camera, 10.5-47mm Lens, Tele IR
Lens Selection Guide:
• Choose NBE-7703-ALX for wider 4MP HDR X area coverage
• Choose NBE-7703-ALXT for long-range 4MP HDR X telephoto monitoring
Compatible Accessories:
• NDA-U-PMAL – Pole Mount Adapter, Large
• NDA-U-CBB – Conduit Back Box, 148mm
• NCA-WLAN-NA – Wireless Installation Dongle, North America
• NPD-3001-WAP – Portable Installation Tool
• NBA-7070-LI – 940nm Invisible IR Module, Wide
• NBA-7070-LIT – 940nm Invisible IR Module, Tele
• NBA-7070-LW – White Light Illuminator Kit, Wide
• NBA-7070-LWT – White Light Illuminator Kit, Tele
• NBA-7070-PFT – Polarizing Filter Kit, Tele
• NBA-7070-PA0 / PA1 / PA2 – Surveillance Cabinet Options
• MSD-064G / MSD-128G / MSD-256G – Industrial microSD Cards
Optional Software & Licensing:
• MVC-IVA-TRA – IVA Pro Traffic
• MVC-IVA-APC – IVA Pro Appearance
• MVC-IVA-PPE – IVA Pro PPE
• MVC-IVA-LPR – IVA Pro License Plate
• MVC-IVA-MMR – IVA Pro Vehicle Make Model
• MVC-IVA-DGS – IVA Pro Dangerous Good Signs
• MVC-IVA-LPRX – IVA Pro License Plate + Make Model
• MVC-IVA-VGD – IVA Pro Visual Gun Detection
• MVC-IAA-GUN – Gunshot Detector License
Default selection is NBE-7703-ALX. Specify NBE-7703-ALXT for long-range telephoto coverage.
