Samsung SNO-1080R IP Network Day Night Security Camera

NOTICE: This product has been discontinued or is EOL - Please contact our Experts or Please search the main category or other related categories.

Samsung SNO-1080R IP Network Day Night Security Camera is a general purpose VGA weatherproof IR camera with a Vari-focal lens from 2.2mm to a 7.7mm and true Day/Night ICR for a wide range of outdoor applications. The SNO-1080R is a powerful VGA camera that is capable of a maximum of 30 frames per second at 640 x 480 resolutions. The IR features 31 LED lights to illuminate the coverage area that is recorded by the device at night to come up with videos with high clarity even with challenging lighting conditions. The device has stunning high definition video streams which supports dual codecs in compressed formats, H.264 and MJPEG. It is transmitted in real time to different monitors and video recording devices. The SNO-1080R camera has Power over Ethernet, Face Detection, IP66, Motion Detection, SSDR, SSNRIII and has been ONVIF conformed. This camera can take up a total power amount of maximum 7 watts consumption of within the operating temperature of 14F degrees to 122F degrees. This security camera that is packed with features all together weighs a total of 1 kilogram.

Samsung SNO-1080R Main Features:

• 30fps at VGA (640x480) resolution
• 2.3~7.9mm (3.4x) varifocal lens
• H.264, MJPEG Dual Encoding
• Multiple Streaming
• Day and Night Function (ICR)
• SSDR, SSNRIII
• Motion Detection, Face Detection
• IP66, PoE, 15ea IR LED (viewable length of 15m)

Samsung SNO-1080R Specifications:

• VIDEO
• Imaging Device 1/4" PS CMOS
• Total Pixels 680(H) x 512(V)
• Effective Pixels 640(H) x 480(V)
• Scanning System Progressive
• Min. Illumination 0.7 lux (F1.2, Color mode), 0 lux (IR LED on, B /W Mode)
• S / N Ratio 50dB
• Video Out DIP connector type, for installation
• LENS
• Focal Length (Zoom Ratio) 2.2 ~ 7.7mm (3.5x) varifocal
• Max. Aperture Ratio F1.2
• Angular Field of View H : 94°(Wide) ~ 26.5°(Tele), V : 70°( Wide) ~ 20°( Tele)
• Min. Object Distance 500mm (1.64ft)
• Mount Type Board type (Ø14)
• OPERATIONAL
• IR LED 15ea
• Viewable Length 15m
• Camera Title Off / On (Displayed up to 15 characters)
• Day & Night Auto (ICR) / Color / B/W / External
• Backlight Compensation Off / BLC
• Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
• Digital Noise Reduction SSNRIII (2D+3D noise filter ) (Off / On)
• Motion Detection Off / On (4 programmable zones)
• Privacy Masking Off / On (32ea 4 points polygonal )
• Sens-up (Frame Integration) Off / Auto (2x ~ 60x )
• Gain Control Off / Low / Medium / High
• White Balance ATW / AWC / Manual / Indoor / Outdoor
• Electronic Shutter Speed Auto / A.FLK / Manual (60x ~ 1/12000sec)
• Flip / Mirror Off / On
• Intelligent Video Analytics Face detection
• Alarm I/O Input 1ea
• NETWORK
• Ethernet RJ-45 (10/100BASE-T)
• Video Compression Format H.264, MJPEG
• Resolution 4 : 3 Mode - 640 x 480 / 320 x 240 / 160 x 120
• Max. Framerate Max. 30fps at all resolutions
• Video Quality Adjustment H.264 : Compression level, Target bitrate level control
• MJPEG : Quality level control
• Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
• Streaming Capability Multiple streaming (Up to 10 profiles)
• IP IPv4, IPv6
• Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
• FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, ONVIF
• Security HTTPS(SSL) login authentication, Digest login authentication,
• IP address filtering, User access log, 802.1x Authentication
• Streaming Method Unicast / Multicast
• Max. User Access 10 users at unicast mode
• ONVIF Conformance Yes
• Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
• Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
• Web Viewer Supported OS : Windows XP / VISTA / 7, MAC OS
• Supported Browser : Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Apple Safari
• Central Management Software NET-i viewer
• ENVIRONMENTAL
• Operating Temperature / Humidity -10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
• Ingress Protection IP66 Grade (Waterproof )
• ELECTRICAL
• Input Voltage / Current DC 12V / 480mA, PoE ( IEEE802.3af ) / 108mA
• Power Consumption Max. 5.6W
• MECHANICAL
• Color / Material Dark gray / ALDC
• Dimensions (WxH) Ø 86.8 x 304.6mm ( Ø3.42" x 11.99" )
• Weight 1Kg ( 2.2 lb )
