Samsung SNO-5080R IP HD Megapixel IR Bullet Security Camera

Write a Review
SKU:
SNO-5080R
Shipping:
Calculated at Checkout
  • Samsung SNO-5080R
  • Samsung SNO-5080R
  • Samsung SNO-5080R
  • Samsung SNO-5080R
$581.00

Description

Samsung SNO-5080R IP HD Megapixel IR Bullet is a powerful 1.3 megapixel Weatherproof Day/Night Security Camera capable of displaying multiple resolutions from CIF 320 x 240 through 16:9 format 720p High Definition, to full 1.3 megapixels 1280 x 1024. The maximum frame rate is 22 frames per second @ 1280 x 1024 and 30 frames per second @ 720p resolution. The IR range will allow it to illuminate objects up to 100 feet away with its DC Auto Iris varifocal lens of 10mm to an ultra wide 2.3mm. It has features like SSNRIII with 2D and 3D filtering, SSDR or Samsung Super Dynamic Range and Privacy Masking in 12 programmable zones. The Samsung SNO-5080R bullet camera has a multi-stream H.264, MPEG-4, MJPEG codec for several locations at the same time, needing different formats. The power of Bi-Directional Audio System will assist the audio transmission not to have delays for real time monitoring to be secured. This IR bullet camera has a True Day/Night operation with ICR and is powered via POE or 24 VAC power source. Together with all of these advanced features, the IR bullet is an ONVIF approved security camera.


Samsung SNO-5080R Main Features:



  • Max. 1.3M (1280 x 1024) resolution
  • Supports 16:9 HD (720p)
  • 100ft of monitoring range in 0 Lux
  • Built-in 2.8~10mm (3.6x) Vari-focal mega lens
  • H.264 / MPEG-4 / MJPEG multiple codecs
  • PoE, IP66

Samsung SNO-5080R Specifications:

  • VIDEO
  • Imaging Device 1/3" 1.3M PS CMOS
  • Total Pixels 1,384(H) x 1,076(V)
  • Effective Pixels 1,329(H) x 1,049(V)
  • Scanning System Progressive
  • Min. Illumination Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
  • B/W : 0Lux (F1.2, 50IRE, IR LED on)
  • S / N Ratio 50dB
  • Video Output DIP connector type, 704 x 480(N), 704 x 576(P), for installation
  • LENS
  • Focal Length (Zoom Ratio) 2.8 ~ 10mm (3.6x) Vari-focal
  • Max. Aperture Ratio F1.2
  • Angular Field of View H : 94.6(Wide) ~ 28.8(Tele), V : 68.4(Wide) ~ 21.6(Tele)
  • Focus Control Manual
  • Lens Type DC auto iris
  • Mount Type Board-in type
  • OPERATIONAL
  • IR LED 31ea
  • Viewable Length 100ft
  • Camera Title Off / On (Displayed up to 15 characters)
  • Day & Night Auto (ICR) / Color / B/W
  • Backlight Compensation Off / BLC / HLC
  • Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
  • Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
  • Motion Detection Off / On (4 programmable zones)
  • Privacy Masking Off / On (12 programmable zones)
  • Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
  • Gain Control Off / Low / Medium / High / Manual
  • White Balance ATW / AWC / Manual / Indoor / Outdoor
  • Electronic Shutter Speed Auto / A.FLK / Manual (1/30 ~ 30,000sec)
  • Flip / Mirror Off / On
  • Intelligent Video Analytics Scene change, Virtual line, Enter / Exit, Appear / Disappear
  • Alarm I/O Input 1ea / Output 1ea (Relay)
  • NETWORK
  • Ethernet RJ-45 (10/100BASE-T)
  • Video Compression Format H.264, MPEG-4, MJPEG
  • Resolution 1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
  • Max. Framerate 22fps (1280 x 1024), 30fps (720P HD)
  • Video Quality Adjustment H.264, MPEG-4 : Compression level, Target bitrate level control
  • MJPEG : Quality level control
  • Bitrate Control Method H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
  • Streaming Capability Multiple streaming (Up to 10 profiles)
  • IP IPv4, IPv6
  • Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
  • FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
  • Security HTTPS(SSL) login authentication, Digest login authentication
  • IP address filtering, User access log
  • Streaming Method Unicast / Multicast
  • Max. User Access 10 users at unicast mode
  • ONVIF Conformance Yes
  • Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
  • Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
  • Web Viewer Supported OS : Windows XP / VISTA / 7, MAC OS
  • Supported Browser : Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Apple Safari
  • Central Management Software NET-i viewer
  • ENVIRONMENTAL
  • Operating Temperature / Humidity -10C ~ +50C (+14F ~ +122F) / up to 80% RH
  • Ingress Protection IP66 Grade (Waterproof)
  • ELECTRICAL
  • Input Voltage 12V DC, 24V AC, PoE (IEEE802.3af)
  • Power Consumption Max. 11W
  • MECHANICAL
  • Color / Material Dark gray / Metal
  • Dimensions (WxHxD) 86.0 x 86.1 x 332.8mm (3.39" x 3.39" x 13.1")
  • Weight 1.3Kg (2.87 lb)
