KTNC K9-A1600 16 channel 960H DVR 480fps

  • KTNC K9-A1600 960H DVR 16ch Highlights
  • KTNC K9-A1600 16 channel 960H DVR Front Panel
  • KTNC K9-A1600 DVR Specifications
  • KTNC K9-A1600 DVR measurements
  • KTNC K9-A1600 physical functions and connections
No Longer Available - Contact Us

Product Description

KTNC K9-A1600 16 channel 960H DVR sets a new standard for the top tier in CCTV video surveillance. The digital video recorder includes the cutting-edge 960H high resolution recording offering over 35 percent more detail that 4CIF or D1 DVR systems. This unit includes real-time 480fps recording in full 960H (960x480 pixel) high resolution ideal for 700TVL security cameras. Across the board the unit includes all the most desired qualities like H.264 compression, a complete set of remote viewing applications and of course local HDMI High Definition output. Users will absolutely enjoy the next level in video security with the premium KTNC DVR.

Locally the unit allows a variety of control methods from its full featured front panel, IR remote control or USB keyboard and mouse support, all options are available. In addition to HDMI output this Digital Video Recorder includes alternative monitor connections including spot monitor. Local back-up via USB or built-in DVD-RW makes life easy and a variety of intelligent benefits are realized in the surveillance software interface. Advantages like the Event Mapper offering graphical event versus time search to PIP functions are all incorporated. Remote viewing is equally satisfying with the full set of options such as the free 1024ch CMS, the full system control and configuration via its remote client or its mobile viewing for IPhone and Android devices.

More perks included in this innovative DVR design cover aspects like multi-protocol PTZ camera support via RS-485, Two Way Audio and I/O Device integration. Sophisticated operations are achieved with ease via its intelligent VMS and the all desired functions like email notifications are also integrated. The KTNC K9-A1600 Digital Video Recorders are a sure pick for maximum benefit from 700TVL security camera systems.

KTNC K9-A1600 Main Features:

  • Linux Embedded 16 channel DVR 960H
  • H.264 Hardware Compression (Dual Streaming)
  • 960H (WD1 960 x 480) 480fps Real-time Viewing, Recording and Playback
  • HDMI 1080P HD Display, VGA and BNC monitor options Plus Spot Monitor
  • Pentaplex Operation (i.e. Simultaneous Viewing, Recording, playback, back-up and remote view)
  • Intelligent DVR Surveillance Software with intuitive functions like a graphical display of time versus event trigger
  • Full Featured Professional: Viewing, Search, Playback and Export Functions (Export via USB or DVD option)
  • DVR Graphical User Interface (GUI) is built with Multi-language support
  • Local Mouse Control, Front Panel and IR Remote Controller
  • Complete Remote Monitoring with Mobile Viewing on IPhone, IPad or Android (Live, Playback and PTZ)
  • Professional Free DDNS, Web Server, Windows 1024ch CMS and MAC Client Software
  • Four (4) Channel Audio Input and (1) Channel Output: Two Way Communication
  • Gigabit LAN Ethernet, Multi-Protocol Network Standard Support
  • RS-485 PTZ Control (USB mouse on-screen and front panel control support)
  • Supports 6TB Total via 2 Internal SATA HDD Slots
  • Built-in DVD burner (Optional – replaces one HDD)
  • Includes: USB Mouse, IR Remote and 4G USB Flash Drive
  • 19” Rack mountable – rack ears included
  • 3 Year Warranty
