KT&C KPC-DN6260PH Day/Night Mini Security Camera

Write a Review
SKU:
KPC-DN6260PH
Shipping:
Calculated at Checkout
  • KT&C KPC-DN6260PH MIni Box Security Camera
  • KT&C KPC-DN6260PH Key Features
  • KT&C KPC-DN6260PH Ultra High Resolution and Image Clarity
  • KT&C KPC-DN6260PH Superior Digital Noise Reduction (DNR)
  • KT&C KPC-DN6260PH Other camera enhancements
  • KT&C KPC-DN6260PH diagram
$159.00

Description

KT&C KPC-DN6260PH Day/Night Security Camera is a high performance mini box style security camera offering superior features in a compact design. The full featured box camera provides 600TVL High resolution imaging and is a True Day/Night Camera with mechanical IR Cut-filter. The Mini Box Camera provides support for C or CS mount style lens of the Auto Iris or Manual type. In addition, attributes like 3D DNR (Digital Noise Reduction) and DSS (Digital Slow Shutter) allow the mini security camera to provide superior low light video surveillance.
KT&C KPC-DN6260PH Day/Night Security Camera also includes Motion Detection with alarm output, has privacy masking and an OSD for easy camera setup and configuration. The camera also supports Dual Voltage for power input from 12VDC or 24VAC Power Supplies. The KPC-DN6260PH Day/Night Security Camera is a unique CCTV camera perfect for a variety of security camera systems requiring small form factor box cameras.

KT&C KPC-DN6260PH Main Features:

Sony 1/3” Super HAD CCD
• 600 TVL Horizontal Resolution
• 3D DNR (Digital Noise Reduction)
• 0.4 Lux / F1.2, (50 IRE), 0.001 Lux@F1.2 (DSS on)
• True Day & Night with ICR Mechanism
• DSS, AGC, BLC, AWB
• BLC (Zone & Level setting)
• Privacy Image masking (8 Zones)
• Multilingual OSD: English, Spanish, French, Portuguese, Japanese
• Motion Detection (Alarm Output)
• C/CS Mount Lens
• DC12V / AC24V dual power


Model KPC-DN6260NH KPC-DN6260PH
Signal System NTSC PAL
Image Sensor 1/3" Sony Super HAD CCD
Scanning System 2:1 Interlace
Scanning Frequency (H x V) 15.734 KHz x 59.94 Hz 15.625 KHZ x 50 Hz
Total Pixels / Effective Pixels 811(H) x 508(V) / 768(H) x 494(V) 795(H) x 596(V) / 752(H) x 582(V)
Horizontal Resolution 600 TVL
Lens Type C/CS Mount / Video / DC / Manual Iris
S/N Ratio More than 52dB (AGC Off)
Min. Illumination 0.0001 Lux / F1.2 (DSS on)
Gamma r = 0.45
Shutter Speed 1/60 ~ 1/100,000 sec 1/50 ~ 1/100,000 sec
Video Output Level 1Vp-p Composite (75O)
Day & Night True Day & Night With ICR Mechanism
OSD Built-in OSD
Function
IMAGE Reverse(H/V), Positive / Negative
Manual Shutter 1/60(50), FLK, 1/250, 1/500, 1/2K, 1/5K, 1/10K, 1/100K (x2, x4, x8, x16, x32, x64, x128,

x256)
Sense-Up (DSS Digital Slow Shutter): Off / Auto (x2, x4, x8, x16, x32, x64, x128, x256)
Iris Control ELC / DC / Video
Gain Control Off / Low / Middle / High
BLC Off / BLC
DNR Off / LOW / MID / HIGH / VERY HIGH (Adaptive 3D + 2D)
AGC OFF / VERY LOW / LOW / MID / HIGH / VERY HIGH
White Balance ATW1 / ATW2 / AWC / MANUAL / (ATW1 : 2500 ~ 9300°K, ATW2 : 2000 ~ 10000°K)
Sharpness Adjustable
Motion Detection Off/ On (Advanced) : (ALARM-OUT)
Privacy Masking Zone 8 ea. (Polygonal Method, 4 Points)
Digital Zoom Off / On (Max X10)
Language NTSC : English, French, Spanish, Japanese, Portuguese
Interface
RS-485 Protocol via Palco-D/P / Vicon / Panasonic / Philips / Erna / Diamond / VCLTP / Kalatel /
Samsung (Baud Rate 2400 / 4800 / 9600 / 19200 / 38400)
Operating Temperature -10 °C ~ 50 °C (14 °F ~ 122 °F)
Storage Temperature -20 °C ~ 60 °C (-4 °F ~ 140 °F)
Humidity Less than 80%RH
Power Supply DC12 (±10%) Max 220mA / AC24 (±10%) Max 2.5W
