Messoa SCR367-HN5 WDR IR Bullet Security Camera 700TVL

Write a Review
Calculated at Checkout
  • Messoa SCR367-HN5 infrared Bullet Camera
  • Messoa SCR367-HN5 key features
  • Messoa SCR367-HN5 camera dimensions


Messoa SCR367-HN5 IR Bullet Security Camera is a premier ultra-high resolution outdoor bullet style camera for professional CCTV Video Surveillance. The unit features a superb Sony CCD image sensor yielding ultra-crisp 700TVL video. The Messoa SCR367-HN5 Infrared Bullet Cameras also including Lumii technology which enhances image clarity in even the most challenging low light conditions. The Infrared Bullet Cameras IR LEDs provide up to a 115ft of IR illumination for absolute night vision even in pitch black environments.  Further advancements such as Wide Dynamic Range (WDR) and Highlight Compensation (HLC) ensure clear details even in the most adverse lighting conditions.
The Messoa SCR367-HN5 WDR IR Bullet Security Camera is outdoor ready with a weatherproof rating of IP66 unit also features a sun-shield and cable feed through bracket. The Messoa SCR367 IR Bullet Security Camera offers additional installation benefits such as OSD (on screen display) and external lens adjustment. The unit also supports dual voltage power input for 12VDC or 24VAC CCTV Security Camera Systems. The Messoa SCR367-HN5 Infrared Bullet Security Cameras are an ideal choice for superior high resolution and night vision CCTV surveillance.

Messoa SCR367-HN5 Main Features:

  • 1/3” SONY Exview HAD CCD II
  • High Resolution 700TVL
  • WDR Wide Dynamic Range
  • HLC High Light Compensation
  • DNR Digital Noise Reduction
  • OSD On-screen Display (Menu)
  • IR Infrared Illumination 35m (115ft)
  • 3.3-12mm Varifocal IR Lens with External Adjustment
  • Weatherproof IP66 w/sun-shield and cable feed bracket
  • Dual Voltage: 12VDC or 24VAC

Messoa SCR367-HN5 Specifications:

Signal System NTSC PAL
Image System
Image Pickup Device 1/3” SONY Exview HAD CCD II
Effective Pixels (HxV) 976 (H) × 494 (V)  976 (H) × 582 (V)
Scanning  System 2:1 Interlace V: 59.94 Hz , H: 15.734KHz 2:1 Interlace V: 50 Hz , H: 15.625 KHz
Sync System Internal/Line lock
Horizontal Resolution 700TVL
f=3.3mm~12mm,F1.4 DC iris varifocal IR-corrected lens
External adjustments (zoom and focus)
View Angle
Gamma Correction 0.45
Minimum Illumination
F1.4 color mode : 0.03 lux@50IRE, 0.015 lux@30IRE,  B/W mode : 0.015 lux@50IRE, 0.0075 lux@30IRE,
IR LED ON:0 lux
S/N Ratio More than 50dB (AGC off)
Iris Control DC
Gain Control  On / Off (selectable)
White Balance ATW / Manual / User / Push / Push lock
Electric shutter  1/60 sec 1/50 sec
Flickerless On /Off (selectable)
BLC Off/ BLC/ HLC (High Light compensation) (selectable)
Day/Night Mode Mechanical (ICR) control (Auto/Color/Forced to BW)
Motion Detection Yes, 4 areas (max)
Privacy Mask Yes, 8 zones (max)
High Light Compensation Yes
ATR* On / Off (selectable)
Multi Language English, Japanese, German, French, Russia, Portuguese, Spanish, Simplified Chinese
Video Output 1Vpp composite output, 75 ohm
IR LED Super power LED 28pcs
IR Wavelength 850nm
IR Distance 35M (115ft)
IR Turn On Status Under 10 lux by photocell auto controlled
LED Life More than 10,000 hours(50°C)
Power Supply
Power Requirement DC 12V & AC 24V ± 10%
Power Consumption 7W (max)
Operating Temperature -10°C ~ 50°C
Operating Humidity 90% MAX
Storage Temperature -20°C ~ 60°C
Storage Humidity 70% MAX
Case Material Metal
Dimension(FxHxD) F82.9mm x 87mm x 205.5mm (3.26"x3.43"x8.09")
Weight 610g (1.36 lbs.) approx.
Sun-shield; Cable management bracket
Compact die-cast aluminum; Tempered Glass
Weatherproof Protection Class IP66

Ordering information SCR367-HN5 SCR367-HP5
