A2Z AZDVR2516HE-C 16ch H.264 DVR System 960H Real-time

Write a Review
  • A2Z AZDVR2516HE-C 16ch H.264 DVR System 960H (960 x 480 pixel) Real-time
  • A2Z AZDVR2516HE-C 16ch H.264 DVR key features
  • A2Z AZDVR2516HE-C 16ch H.264 DVR dimensions
No Longer Available - Contact Us


A2Z Security Cameras AZDVR2516HE-C 16ch DVR System is a revolutionary new high performance Linux embedded Digital Video Recorder for real-time, superior high resolution CCTV surveillance. The AZDVR2516HE-C Stand-alone 16ch DVR is a Linux embedded unit that supports higher than D1 video recording with the new 960H (960 x 480 pixel) high resolution standard. The DVR additionally provides this superb resolution in Real-time 480fps for flawless video security. Enhanced with the H.264 video compression the system delivers the highest quality video with optimized bandwidth reduction. The A2Z AZDVR2516HE-C Digital Video Recorder allows Pentaplex multi-function operation for simultaneous system task. The devices is well prepared for local viewing with multiple monitoring outputs including HDMI for HD High Definition 1080P monitors.
The AZDVR2516HE-C is a best in class unit packed with features for truly professional security camera systems. Like local monitoring the DVR System enables flexible remote viewing access including support for various mobile devices like IPhone, Android, Blackberry and more. Additional Support for Two Way Audio, Alarm Sensor integration, Event Triggers, DDNS and a built-in RS-485 interface make for versatile system designs. The units Remote Access support for CMS and IE browser allow complete DVR function including configuration for simple multi-site management. The solution further provides DVD-RW, easy to use GUI including E-map and many other advantages like email notification.

A2Z AZDVR2516HE-C Main Features:

  • 16ch Real-time 480FPS Full 960H High Resolution Recording
  • 960 x 480 pixel 960H resolution recording provides higher quality than D1 (4CIF)
  • Advanced H.264 Video Compression for High Quality Video plus low bit rate
  • Real-time 480fps Video Monitoring and Recording in Full Resolution (960H)
  • Dual Streaming for individual configuration remote access bandwidth
  • Innovative and User-Friendly GUI (Graphical User Interface)
  • Supports Multi-mode Recording allowing alarm combinations from motion, sensors, manual, etc.
  • 16ch Playback Supported and Search via Calendar/Time or Event (sensor, motion, etc.)
  • Triple Back-up options including USB, DVD-RW or Network
  • Pentaplex Operation for simultaneous live monitoring, recording, playback, back-up, remote viewing
  • DHCP, DDNS, PPPoE network protocol support
  • Supports CMS and IE Remote Viewing, Playback, Back-up, PTZ and system configuration
  • Multiples of simultaneous Online Users, with User Authorization Management
  • HDMI 1080P HD True High Definition display supported
  • PTZ Multi-protocol Support with presets (128 total) and auto cruise (8 total)
  • Advanced Smart Phone Mobile Viewing from Windows Phone, Symbian, Android, Blackberry, IPhone
  • Complete SDK upon special request, easy to integrate open architecture
  • Default Selection AZDVR2516HE-C2TB 2TB Surveillance Class Hard Drive

AZDVR2516HE-C Specifications:

Video Compression: High Profile H.264 Standard
Processor: Cortex A9 Dual Core
Operating System: Stand-alone Linux Embedded
Video Input: BNC x 16
Video Output: 2 x BNC Main & Spot Monitor, 1 x VGA, 1 x HDMI
Audio Input: RCA x 4
Audio Output: RCA x 1
Superior Recording Resolution: 960H/D1/CIF
960x480/74x480/352x240 (NTSC) or 960x576/704x576/352x288 (PAL)
Recording Frame Rate: 480fps Real-time Full Resolution
Record Bit Rate: 128K-2Mbps
Encoding: VBR or CBR
Recording Quality: 5 Levels
Recording Modes: Manual, Timer, Motion, Sensor
File Manager: Lock, unlock, reserving time, redundancy
Full Channel Playback: 16ch
Playback Search Modes: Time/Calendar Search, Event (motion, external sensor)
Playback Supports Smart Search for Color Code display of channel recording
Playback Function: Play, Pause, Fast Forward, Rewind, Digital Zoom
Alarm Mode: Sensor, Motion, Video Loss
Alarm Inputs: 16ch
Alarm Output: 1ch
Triggers: Record, PTZ Move, Alarm out, email, etc.
Network Interface: RJ45
Network Protocols: TCP/IP, UDP, DHCP, DNS, PPPoE, DDNS, Email
Network Users: 10 simultaneous online users, Dual Streaming
Mobile Viewing: IPhone, Android, Blackberry, Windows Phone, Symbian
Mobile Functions: Multi-Screen (certain devices), record, snapshot, PTZ Control, Save device list
Support for Two SATA Hard Drives (2x)
PTZ Control: RS-485 x 1 Also Supports Keyboard
USB x 2: Mouse Support, Back-up Function
Remote Controller Included
DC 12V Power Supply
Dimensions: 430mm x 300mm x 55mm (W x D x H)
Operating Temperature: 0-50C, 10-90% Humidity
