Samsung SNP-6201 1080P HD PTZ Camera 20x

  • Samsung SNP-6201 PTZ Surveillance Camera
  • Samsung SNP-6201 PTZ Surveillance Camera
Call us today

Product Description

NOTICE: This product has been discontinued or is EOL - Please contact our Experts or search the category link below or other related categories.


Samsung SNP-6201 20X HD PTZ Camera is the latest version of Samsung high definition 1080P Pan/tilt/Zoom camera systems. The Pan/Tilt/Zoom network based surveillance camera features a progressive scan 2 megapixel CMOS image sensor and an array of intelligent functions and enhancements. Users enjoy multi-streaming of H.264 and MJPEG video compression methods and unit can provide full 1080P HD Video at Real-time 30fps. With WDR (Wide Dynamic Range) and real day/night function the units overcomes even the most challenging lighting. Added Samsung image processing technology such as SSDR, SSNRIII and Sens-up ensure vividly clear IP video surveillance. O

The SNP-6201 Samsung PTZ Camera is among the most versatile speed dome style security cameras available. It offers endless 360 degree rotation and an extended tilt range. Superior Accuracy and up to 255 preset positions are supported while high speed movement is also top class. Flexibility in integration is supported as this unit can also accommodate RS-485 and RS-422, multiple protocol PTZ control. The unit is outfitted with a motorized 20x optical zoom lens that can identify subjects at 180 feet away. All together its pan/tilt/zoom functions are industry leading and include high quality components for reliable long-term operation.

Samsung SNP-6201 PTZ Surveillance Camera is a highly advanced unit offering not only Two Way Audio, Alarm I/O integration or SD Memory card slot. Those functions are included, however a more notable attribute is embedded Video Analytics allowing highly sophisticated, effective and automated detection methods. A variety of event, alert and notification functions are also supported. The PTZ Cameras also integrate via ONVIF or direct support with a variety of leading NVR systems. Some other benefits include flexible installation design, such as support for a variety of mounts including a vandal proof IK10 housing to meet all types of security project needs. Power input is also easy with PoE+ allowing the entire camera to be installed with a single network cable or use 24VAC a common power source for PTZ security camera systems.

Samsung SNP-6201 Main Features:

  • Imaging device 1/3" 2MP Progressive Scan CMOS Sensor
  • Video Compression(w/Bitrate Control): H.264 (MPEG-4 part 10 / AVC - CBR and VBR), MJPEG (VBR)
  • High Definition 2 Megapixel 1920 x 1080P (Full HD), SXGA (1280 x 1024), HD 720p, SVGA, VGA, QVGA
  • Min. illumination Color : 1.5Lux (F1.6, 50IRE), B/W : 0.1Lux (F1.6, 50IRE) (before enhancements)
  • Real-time 30fps 1080P HD and 15fps real-motion when WDR activated
  • 20x Optical Zoom(4.45 ~ 89mm) Lens - Motorized DC auto iris with focus control
  • Pan/Tilt Range: 360 Degrees Endless / 210 Degrees (-15 ~ 195 Degrees )
  • Pan/Tilt Speed Preset: 500 Degrees/sec, Manual : 0.024 Degrees/sec ~ 120 Degrees/sec
  • Preset Positions: 255 with Pan/Tilt/Zoom Accuracy: ±0.2°
  • True Day/Night: Automatic ICR, Color or B/W modes
  • Backlight Compensation Off, BLC, HLC, WDR
  • WDR - Wide dynamic Range: 60dB
  • Contrast enhancement SSDR (Samsung Super Dynamic Range): (Off or On)
  • Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off, Low, Medium or High)
  • Digital image Stabilization (DIS): Off / On
  • Shutter speed settings, Gain Control and White Balance
  • Motion detection: Yes (4 each)
  • Privacy Mask: Off / On (12 zones)
  • Sens-up:(2x ~ 60x)
  • intelligent Video Analytics: Tampering, Virtual line, Enter/Exit, Appear/Disappear, Audio detection, Face Detection (5ea)
  • Alarm I/O input 4 inputs, 2 outputs
  • Composite video output for installation lens
  • PTZ Remote Control interface RS-485/422
  • Multiple Protocol Support: Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE
  • Alarm Triggers Alarm input, Motion detection, Intelligent video analytics, Network disconnect
  • Alarm events: File upload via FTP or Email, Notations via Email or TCP
  • Local storage (SD/SDHC Card Recording with multiple record modes
  • Audio Communication: Bi-directional audio (Two-way) Audio Compression: G.711 u-law, G.726
  • Operating Temperature: -10°C ~ +55°C (+14°F ~ +131°F) Humidity 20% ~ 80% RH
  • Ivory Color with Plastic Casing
  • dimensions (WxH) 152.0 x 218.0mm (5.98" x 8.58")
  • Weight 1.8Kg (3.97 lb)




Mounting Accessories:

Hanging Pendant Mount Adapter

PTZ Camera Outdoor IP66 IK10 Dome Housing (w/Heater/Blower)

PTZ In-ceiling Flush Mount Housing


Moved to EOL February 24, 2020
