Samsung SNP-3120 12x IP Network PTZ Dome Security Camera

Write a Review
SKU:
SNP-3120
Shipping:
Calculated at Checkout
  • Samsung SNP-3120
  • Samsung SNP-3120
  • Samsung SNP-3120
  • Samsung SNP-3120
  • Samsung SNP-3120
$790.00

Description

Samsung SNP-3120 12x H.264 Network PTZ IP is a Wide Dynamic Range (WDR) security camera with lots of features and a very economical price. This Indoor dome PTZ has a wide view range with a 3.6mm to an outstanding 44.3mm for 12x optical zooming capacity and a 16x digital zoom lens is an important part in reaching its target as it has the ability to be zoomed in. No matter how far the target may get, the camera is set to stay focus. This camera has a VGA resolution at 30 fps. The SNP-3120 supports multiple codec system including H.264, MPEG-4 and MJPEG compression formats with bi-directional audio. This makes data transmission not only in time with videos but also in real time audio. As a matter of fact, this data stays unharmed even if it has passed electric currents along with the process. A maximum of 30 frames per second in 4CIF resolution, the camera works flawlessly in maintaining high definition video outputs. The PTZ camera XDR feature or the Extreme Dynamic Range is videos taken in wider range still gets the definition that is clear enough for a decent viewing. The panning is endless at 360 degrees and tilting at -5 to 185 degrees both moving at 650 degrees per second. The SNP-3120 security camera is a dome style network camera dimension of 6.85" x 6.61”. This light camera only weighs a total of 1.2 kg which is light enough that you would not think it is packed with a lot of features.


Samsung SNP-3120 Main Features:



  • Real-time 30(25)fps at 4CIF
  • 12x optical zoom, 16x digital zoom
  • H.264 / MPEG4 / MJPEG multiple codec
  • PoE Plus, SD memory, bi-directional audio support


Samsung SNP-3120 Specifications:



  • Imaging Device 1/4" Ex-view HAD PS CCD
  • Total Pixels 811(H) x 508(V)
  • Horizontal Resolution Color : 600 TV linesCCD
  • Min. Illumination Color : 0.7 Lux (F1.65, 50IRE), 0.001 Lux (Sens up 512x), B/W : 0.07Lux (F1.65, 50IRE), 0.0001 Lux (Sens up 512x)D"
  • S / N Ratio 50dB
  • Lens
  • Focal Length (Zoom Ratio)- 3.69~44.32mm (12x)
  • Max. Aperture Ratio- F1.65(Wide) / F2.01(Tele
  • Angular Field of View- H : 54.44(Wide) ~ 4.62(Tele) / V : 42.32(Wide) ~ 3.58(Tele)
  • Min. object Distance- 0.2m (Wide) / 0.8m (Tele
  • Focus Control- AF / One-Shot AF / Manual
  • Lens Type- DC Auto Iris
  • PAN / TiLT / RoTATe
  • Pan Range- 360 Endless
  • Pan Speed- Preset : 650/sec, Manual : 0.05/sec ~120/sec (Turbo:200/sec)
  • Tilt Range- -5~185
  • Tilt Speed- Preset : 650/sec, Manual : 0.05/sec ~120/sec
  • Preset- 255 ea
  • Preset Accuracy- ±0.1
  • OPERATIONAL
  • on Screen Display- English, French, German, Spanish, Italian, Korean, Portuguese
  • Camera Title- Off / On (Displayed up to 12 characters)
  • Day & Night- Auto (ICR) / Color / B/W
  • Backlight Compensation- Off / BLC / WDR
  • Wide Dynamic Range- 128x
  • Dynamic Range- XDR(extended Dynamic Range) (Off/Low/Medium/High)
  • Digital Noise Reduction- Motion Adaptive 2D+3D Noise Filter (Off/Low/Medium/High)
  • Digital image Stabilization- Off/On
  • Motion Detection- Yes
  • Privacy Masking- Off/On (12 Polygonal programmable zones)
  • Sens-up (Frame integration)- Off / Auto (2x ~ 512x
  • Gain Control- (Off /Low / Medium / High / Manual)
  • White Balance- ATW (In) / ATW (Out) / AWC / Manual
  • electronic Shutter Speed- Off / A.FLK / Manual (1/120 ~ 1/10Ksec)
  • Digital Zoom- 16x
  • Flip / Mirror- Digital Flip
  • VPS- Off/On
  • intelligent Video Analytics- Moved/Fixed
  • Alarm i/o- Input 2ea / Output 2ea (Relay)
  • Remote Control interface- RS-485, CCVC(PELCO Coaxitron)
  • RS-485 Protocol- SAMSUNG T/E, PELCO-P/D, Panasonic, Honeywell, AD, Vicon, GE, Bosch
  • NETWORK
  • ethernet- RJ-45 (10/100BASE-T)
  • Video Compression Format- H.264, MPEG4, MJPEG
  • Resolution- 704 x 480, 640 x 480, 352 x 240, 320 x 240
  • Max. Framerate- 30fps
  • Video Quality Adjustment- H.264 / MPEG4 : Compression Level, Target Bitrate Level Control, MJPEG : Quality Level Contro
  • Bitrate Control Method- H.264 / MPEG4 : CBR or VBR, MJPEG : VBR
  • Streaming Capability- Multiple Streaming (Up to 10 Profiles)
  • Audio i/o- Line In/Line Out
  • Audio Compression Format- G.711 u-law
  • Audio Communication- 2-way
  • iP- IPv4, IPv6
  • Protocol- TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
  • FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS
  • Security- HTTPS(SSL) Login Authentication, Digest Login Authentication, IP Address Filtering, User access Log
  • Streaming Method- Unicast/Multicast
  • Max. User Access- 10 users at Unicast mode
  • Memory Slot- SD/SDHC Memory Slot
  • ONVIF Conformance- Yes
  • Web Viewer- Supported OS : Windows XP / VISTA / 7, MAC OS
  • Supported Browser : Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Apple Safari
  • Central Management Software- NET-i viewer
  • ENVIRONMENTAL
  • operating Temperature / Humidity- SNP-3120 : -10C ~ +50C (+14F ~ +122F) / Less than 90% RH , SNP-3120V /
  • SNP-3120VH : -50C ~ +50C (-58F ~ +122F) / Less than 90% RH
  • ELECTRICAL
  • input Voltage / Current- 24V AC, PoE+ (IEEE 802.3at)
  • Power Consumption- SNP-3120 : Max. 15W
  • MECHANICAL
  • Color / Material- SNP-3120 : Ivory / Plastic, SNP-3120V : Ivory / Aluminum (Vandal-Resistant type)
  • Dimension (WxHxD)- SNP-3120 : Ø174 x 168mm (Ø6.85" x 6.61")
  • Weight- SNP-3120 : 1.2Kg (2.65 Ib)
