Dahua HDW2220M 1080P HD CVI IR Ball Security Camera IP66

Write a Review
SKU:
HDW2220M
MPN:
HDW2220M
  • Dahua OEM HDW2220M 1080P HD CVI IR Ball Security Camera
  • Dahua OEM HDW2220M HD CVI IR Ball Cam Dimensions and Accessories
Contact Us for Replacements

Description

NOTICE: This product has been discontinued or is EOL and therefore in most cases no longer available - Please contact our Experts or search the category link below for related categories.

https://www.a2zsecuritycameras.com/cctv-security-cameras.html

Dahua OEM HDW2220M 1080P HD CVI IR Ball Security Cameras are a new age edition of the high popular "Eye Ball" type CCTV Camera, except now with full HD resolution. Equipped with a 2.4 Megapixel HD Image Sensor this HD CCTV unit boast real-time 30fps 1080P HD video. Thanks to true ICR Day/Night function and a Smart IR LED array the unit likewise offers that high definition video surveillance even in zero light. Various image enhancements are also included and with the 3.6mm lens a nearly 90 degree horizontal viewing angle promises wide area coverage. Easy installation and positioning whether it be ceiling, wall or an angled mounting surface, the device is also outdoor ready with extended operating range thus ready to meet the challenges of countless applications.

Dahua OEM HDW2220M Main Features:

  • 1/2.8" 2.4 Megapixel HD CMOS Image Sensor
  • Real-time 30fps at 1080P or up to 60fps 720P HD
  • Day/Night (IR Cut-Filter), AWB, AGC, BLC, 3D-DNR (Digital Noise Reduction)
  • Smart IR LED Illumination to 20 meters (about 60ft)
  • 3.6mm fixed lens 88º HFOV (6mm, 8mm special order)
  • CCTV Real-time long distance transmission via coax
  • OSD Menu, control communication over coax cable
  • Weatherproof IP66 outdoor rated
  • Low Power: 12VDC at 3.5 watts max consumption
  • Dimensions Φ3.7" × 3.13"
  • Weight 0.77 lbs.
  • NOTE: OEM and Branded Dahua Units Available for Most Models

Small Size, Big performance:
Despite an amazing price tag and compact construction, this HD-CVI IR Ball Camera yields a winning combination of key features that ensure an impressive surveillance. Delivering in real-time 1080P HD at 30fps or an even higher speed 720P HD at 60fps the fluid motion of images is easily noticed compared to IP cameras. The device employs other beneficial technologies like an OSD (on-screen display) Menu that is controlled via coaxial communication allowing remote settings of image settings and beyond. The Added True Day/Night, AWB, wide shutter speed range, BLC and especially 3D DNR (Digital Noise Reduction) guarantee excellent clarity in all sorts of challenging lighting. Smart IR LED night vision produces a 20 meter or roughly 60ft infrared illumination and the smart feature ensures it doesn't over expose objects in the scene. Wide angle coverage with a 3.6mm Megapixel lens provide 88º of horizontal coverage while 6mm and 8mm units can be special ordered for more telephoto shots.

Simple Design, Amazing abilities:
In addition to the Dahua HDW2220M HD CVI IR Ball Cameras having high performing video, a compact outdoor design that IP66 weatherproof or its inconceivable low cost, these Dahua (or OEM versions) include a great quality that can be expected to last and includes extended warranty. By the nature of its design it offers a discreet video security solution for indoor and outdoor projects. The free twisting Ball design if not flexible enough alone can also be acquired with optional mounts to help achieve various task like L-type wall mounts or pole mount adapters. Supporting the same style of install as traditional CCTV systems you can rely on an easy installation using even existing coaxial cabling if available, a common 12VDC power source and the same BNC connectors.

Last Updated March 25, 2016
