A2Z AZIR130 LED Infrared Illuminator

  • Image 1
Price:
$105.00
SKU:
AZIR130
Brand:
Shipping:
Calculated at checkout
Quantity:


Product Description

A2Z AZIR130 LED Infrared Illuminator is an outdoor unit with 132 High Intensity IR LEDs. The AZIR130 IR Illuminator is built in a weatherproof aluminum casing rated to IP66 environmental standards. The unit provides an impressive IR Illumination range of up to 200ft in a 45 to 50 degree spread. The unit includes a sun shield and utilizes a photocell for automatic IR LED ON/OFF power control. The A2Z AZIR130 IR Illuminator has optional 12VDC or 24VAC models available. The AZIR130 allows extended operating temperatures from -22 to 140 degrees Fahrenheit. Infrared Illumination produced to the 850nm range makes the AZIR130 perfect for added night vision to True Day Night Security Cameras. The IR Device also supports a variety of standard camera mounts for easy indoor or outdoor system installation.

A2Z AZIR130 MAin Features:

  • Infrared Illuminator with 132 IR LEDs
  • Weatheroproof IP66 (Outdoor) w/ Sunshield
  • IR Illumination up to 200 Feet
  • Aluminium Case with Extended Temperature Range
  • Power: DC 12V or Optional AC 24V model Draw: 1200mA

A2Z AZIR130 Specifications:

  • IR LED Count: 132 high power units
  • IR LED Wavelength: 850nm Semi Covert
  • IR Projected Angle 45°+50°
  • Emissive Power 18W
  • Effective IR Distance up to 200 Feet
  • Photocell Control CDS/10Lux
  • Power Supply:DC 12V +/- 10% or Optional AC 24V Model
  • Current Consumption 1200mA
  • Storage Temperature -30~+60C (-22 to 140F)
  • Operating Temperature -30~+60C (-22 to 140F)
  • Environmental: IP66 Weatherproof (Outdoor)
  • Construction: Aluminum Casing
  • Dimension 119X108X141(mm)
  • Weight 800g
