Samsung

Samsung SND-1011 IP Network Color Dome Security Camera

Write a Review
SKU:
SND-1011
Shipping:
Calculated at Checkout
  • snd-1011, samsung, vga, network, fixed, 3mm, dome, camera,
  • snd-1011, samsung, vga, network, fixed, dome, camera,
  • snd-1011, samsung, vga, network, fixed,  dome,
$204.00

Description

Samsung SND-1011 is a compact design POE security camera with a network VGA resolution, Fixed-lens (3mm) Dome style and features the Samsung WiseNetS DSP with a cost effective price. This is a perfect solution to surveillance with a need for a small footprint and up to 30 frames per second at VGA (640x480) resolution. Dual encoding power of the camera makes it possible for the camera to stream to multiple monitors. Dual Codecs include H.264 and MJPEG formats. Advanced features come with Samsung Techwin’s WiseNetS DSP microchip is a powerful one and comes with SSNRIII, SSDR, Polygonal Privacy Masking and face detection technologies. The SSNR cleans out the output as it is set to reduce the noise levels in the camera. The SSDR adjusts the camera to different lighting conditions. Face detection on the other hand, lets the camera focus on a certain point where there is the visibility of a human face. This fixed dome camera can be used as an analog camera or network device. Contrast enhancement is the camera day/night function to make sure that there is the right balance of lighting and contrast given the difference of conditions. Dark areas and super light areas are regarded equally by the device. Plus, it does come in an extremely light material at .63 lbs which speaks about the product being light in weight but heavy in features such as the on board SD memory slot.



Samsung SND-1011 Main features:

  • Max. 30fps at VGA resolution
  • Built-in 3mm fixed lens
  • H.264, MJPEG dual codec
  • PoE, SD memory

Samsung SND-1011 Specifications:

  • VIDEO
  • Imaging Device 1/4" PS CMOS
  • Total Pixels 680(H) x 512(V)
  • Effective Pixels 640(H) x 480(V)
  • Scanning System Progressive
  • Min. Illumination 0.7Lux (F1.2)
  • S / N Ratio 50dB
  • Video Out DIP connector type, for installation
  • LENS
  • Focal Length (Zoom Ratio) 3mm fixed
  • Max. Aperture Ratio F2.0
  • Angular Field of View H : 70, V : 50
  • Min. Object Distance 40mm (0.13ft)
  • Mount Type Board type
  • PAN / TILT / ROTATE
  • Pan Range 0 ~ 355
  • Tilt Range 17 ~ 90
  • Rotate Range 0 ~ 355
  • OPERATIONAL
  • Camera Title Off / On (Displayed up to 15 characters)
  • Day & Night Auto (S/W) / Color / B/W / External B/W
  • Backlight Compensation Off / BLC
  • Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
  • Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
  • Motion Detection Off / On (4 programmable zones)
  • Privacy Masking Off / On (32ea 4 points polygonal)
  • Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
  • Gain Control Off / Low / Medium / High
  • White Balance ATW / AWC / Manual / Indoor / Outdoor
  • Electronic Shutter Speed Auto / A.FLK / Manual (60x ~ 1/12000sec)
  • Flip / Mirror Off / On
  • Intelligent Video Analytics Face detection
  • Alarm I/O Input 1ea
  • NETWORK
  • Ethernet RJ-45 (10/100BASE-T)
  • Video Compression Format H.264, MJPEG
  • Resolution 4 : 3 Mode - 640 x 480 / 320 x 240 / 160 x 120
  • Max. Framerate Max. 30fps at all resolutions
  • Video Quality Adjustment H.264 : Compression level, Target bitrate level control
  • MJPEG : Quality level control
  • Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
  • Streaming Capability Multiple streaming (Up to 10 profiles)
  • IP IPv4, IPv6
  • Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
  • FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, ONVIF
  • Security HTTPS(SSL) login authentication, Digest login authentication
  • IP address filtering, User access log, 802.1x Authentication
  • Streaming Method Unicast / Multicast
  • Max. User Access 5 users at unicast mode
  • Memory Slot Micro SD/SDHC memory slot
  • ONVIF Conformance Yes
  • Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
  • Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
  • Web Viewer Supported OS : Windows XP / VISTA / 7, MAC OS
  • Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
  • Central Management Software NET-i viewer
  • ENVIRONMENTAL
  • Operating Temperature / Humidity -10C ~ +50C (+14F ~ +122F) / 20% ~ 80% RH
  • ELECTRICAL
  • Input Voltage / Current 12V DC / PoE (IEEE802.3af)
  • Power Consumption Max. 5W
  • MECHANICAL
  • Color / Material Ivory / Plastic
  • Dimensions (WxH) 107.6 x 83.7mm (4.24" x 3.3")
  • Weight 285g (0.63 lb)
