Samsung SCZ-3430 WDR 43x Zoom Security Camera

Product Description

Samsung SCZ-3430 WDR 43x Zoom Security Camera is a ultra high grade model for superior video monitoring. The Zoom camera boast vivid 600tvl and 700tvl High Resolutions while offering unsurpassed 43x motorized zoom lens. The camera is built with the powerful Sony Ex view HAD CCD with double scan for True Wide Dynamic Range performance. The Samsung Zoom Security Camera SCZ-3430 is further enhanced with powerful technology including DIS, Sens Up, SSNR III and other image settings for best in class video surveillance. The Samsung 43x Day/Night Zoom Camera supports both coaxil and RS-485 communication and control. The SCZ-3430 can be used as a stand alone zoom camera or as part of customized Pan Tilt Zoom (PTZ) Security Camera Systems. The Samsung SCZ-3430 WDR Zoom Security Camera also support dual voltage for 24VAC or 12VDC power input. This CCTV Zoom Camera additionally offers built in intelligent video, alarm output and is constructed in a high quality metal casing. The unit is perfect for indoor or outdoor application when used with a camera housing.

Samsung SCZ-3430 Main features:

High resolution of 600TVL (Color), 700TVL(B/W)
Min. illumination B/W : 0.07Lux@F1.65 or 0.0002Lux (Sens-up, 512x)
Powerful 43x motorized zoom lens (3.2 ~ 138.5mm), Digital 16x
True Day/Night (ICR) IR Cut Filter
True Wide Dynamic Range, VPS, DIS, Sens Up
Intelligent video, MD, DNR (3D+2D)
Coaxial control (CCVC) or RS-485 Communication
Dual power, 24VAC & 12VDC

Samsung SCZ-3430 Specifications:

Imaging Device: 1/4" Ex-view HAD CCD (Double scan)
Total Pixels: NTSC 811(H) x 508(V) PAL 795(H) x 596(V)
Effective Pixels: NTSC 768(H) x 494(V) PAL 752(H) x 582(V)
Scanning System: 2 : 1 Interlace
Synchronization: Internal / Line lock
Frequency: H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Horizontal Resolution: Color : 600TV lines, B/W : 700TV lines
Min. Illumination:
Color : 0.7Lux@F1.65 (50IRE), 0.001Lux (Sens-up, 512x)
B/W : 0.07Lux@F1.65 (50IRE), 0.0002Lux (Sens-up, 512x)
S / N Ratio 52dB (AGC off, Weight on)
Video Output: CVBS : 1.0 Vp-p / 75O composite
Focal Length: (Zoom Ratio) 3.2 ~ 138.5mm (Optical 43x)
Max. Aperture Ratio: 1: 1.65(Wide) ~ 3.7(Tele)
Angular Field of View: H : 61.22°(Wide) ~ 1.47°(Tele) / V : 47.16°(Wide) ~ 1.1°(Tele)
Min. Object Distance: 1m (3.28ft)
Focus Control: Auto / Manual / One AF
Zoom Movement Speed: 3.2sec (Wide to tele)
On Screen Display
NTSC: English, Japanese, Spanish, French, Portuguese, Taiwanese, Korean
PAL: English, French, German, Spanish, Italian, Chinese, Russian, Polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese
Camera Title Off / On (Displayed 54 characters)
Day & Night ICR: Day / Night / Auto / Ext
Backlight Compensation Off / On (Area setting)
Wide Dynamic Range: 128x (52dB): SCZ-3430 160x (52dB): SCZ-3430
Contrast Enhancement: XDR (Off / Low / Mid / High)
Digital Noise Reduction: Adaptive 3D+2D (Off / Low / Mid / High / User)
Digital Image Stabilization DIS: Off / On
Motion Detection: Off / Tracking / Detection
Privacy Masking: Off / On (12 programmable zones with polygonal masking)
Sens-up: (Frame Integration) 2x ~ 512x
Gain Control: Off / On
White Balance: ATW1 / ATW2 / AWC (Manual) / 3200K / 5600K
Electronic Shutter Speed: 1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Digital Zoom: Off / On (1x ~ 16x)
Flip: Off / H / V / H/V
Profile: Standard / ITS / Backlight / Day & Night / Gaming / Custom
VPS: Off / On
Intelligent Video: Fixed / Moved
PIP: Off / On
Schedule: Day / Time
Alarm: 1 Out
Communication: Coaxial control or RS-485
Protocol Coax : CCVC
Protocol RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon
Operating Temperature / Humidity -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH
Input Voltage: Dual (24VAC & 12VDC ±10%)
Power Consumption Max. 3.0W
Color / Material: Silver / Aluminum, Steel
Dimensions (WxHxD): 59.0 x 59.0 x 154.2mm (2.32" x 2.32" x 6.07")
Weight 564g (1.24 lb)
