Samsung SCU-2370 37x PTZ camera system

Samsung SCU-2370 PTZ camera system is a traditional style Pan/tilt/Zoom Camera incorporating the latest advancements in CCTV video surveillance. The positioning system is an integrated pan/tilt, camera with housing and motorized zoom lens. The Samsung SCU-2370 PTZ Camera also produces ultra-sharp 600TVL and 700TVL high resolution video. Powerful Image enhancements from the Samsung W-V DSP chipset like SSDR, SSNRIII, Sens-up and HLC (highlight compensation) ensure vividly clear imaging anytime. The units ICR Day/Night operation paired with Sens-up delivers increibly low light surveillance to 0.00004 lux.

The PTZ positioning system is built for rugged requirements, the high quality design ensure fluid movement and absolute precision even in high winds. Built to handle all types of weather, the Samsung PTZ camera SCU-2370 has an IP66 class water proof rating. Unlike Dome style PTZ cameras, the unit can provide not only endless 360 degree pan, but a superior tilt range of -85 - 40 degrees. Users enjoy it above standard speed and functions like an integrated wiper to clear the cameras view from debri, rainm, snow or otherwise.

All of the best qualities, performance and reliabilty can be found in this innovative Samsung Pan/Tilt/Zoom Camera. Multi-language On-screen display, flexible PTZ interface for coaxil or RS-485 control with multi-protocol support to presets, alarm I/O and other factors all add to the top tier status of this unit. For professional grade surveillance systems and security camera systems, there is simply no better choice for strict, outdoor active security patrol.

Samsung SCU-2370 Main Features:

1/4" Super HAD CCD Image Sensor
37x optical Zoom (3.5 - 129.5mm)
Outdoor Weatherproof IP66 Integrated Pan/Tilt/Zoom Camera System
True Day/Night opeation Color: 0.2 Lux / B/W: 0.02 Lux
Sens-Up Low Light Imaging: Color 0.0004 Lux / B/w: 0.00004 Lux
Samsung Super Dynamic Range (SSDR): contrast enhancement
Samsung Super Noise Reduction 3rd Generation (SSNRIII): noise reduction
Digital Image Stabilization: DIS
Sens-up: 2x - 512x
Highlight Compensation (HLC)
Multi-protocol support: Pelco, Samsung, Panasonic, Bosch, Vicon, AD, GE, Honeywell
Flexible PTZ control interface: RS-485 or coaxil control supported
Motion Detection, Privacy Masking, Defog, Alarm, and Schedule functions
IR illuminator optional control and Aux control for integrated Wiper pump
360 Degree Endless Pan, -85 - 40 Degree Tilt with superb 0.1 accuracy and 255 presets
Max High Speed Pan: Preset 120 / Manual 36 / Turbo 120 Degrees per second
Max High Speed Tilt: Preset and Manual 36 degrees per second
Operating Temperature / Humidity -50°C ~ +50°C (-58°F ~ +122°F) / Up to 100% RH
Input Voltage 24V AC ±10% Power Consumption Max. 40W / 144W (Fan & heater on)
Construction: Color: Ivory / Material: Aluminum
Dimensions (WxHxD) 217.3 x 587.5 x 500.0mm (8.56" x 23.13" x 19.69")
Weight 17.5Kg (38.58 lb
