Description
The Milesight VE0601-A is a 16-channel enterprise-class NVR appliance designed to deliver scalable, reliable, and high-performance VMS based surveillance solutions. Housed in a 2U chassis, it supports up to 6 HDDs for a total of 120TB possible raw storage and has a 256GB M.2 SSD for Windows OS stability.
Powered by a 2.0GHz Intel Celeron processor and dual-channel 8GB DDR4 RAM (expandable to 16GB), this Windows 10 IoT Enterprise-based system comes preloaded with Milesight VMS Enterprise and licenses for 16 IP camera channels. Delivering true Server / Client Video Management System software advanced functions are realized across numerous aspects such as N+M failover. Further intuitive PC Client Software and Mobile Applications are packed with capabilities rivaling any of the world leading VMS solutions.
It offers robust video performance with up to 12MP resolution and supports MJPEG, H.264, and H.265 formats. Display output includes HDMI and DisplayPort with support for independent or synchronized dual-display output. Network redundancy is ensured through four 2.5GbE ports and high bandwidth throughput, make it ideal for complex enterprise networks. Even more, the Milesight VE0601-A 16ch NDAA VMS appliance provides all this and plenty more in a solid, purpose built device for top-tier security camera system performance at the best price.
✨ Key Features
- 16CH IP camera licenses included
- Windows 10 IoT Enterprise (64-bit)
- Advanced Client/Server Architecture
- AI Analytics, Smart Search & Playback Functions
- Intuitive Interface Designs - PC Software, Mobile Apps Included
- VMS Software Upgrades Included
- Supports up to 12MP video resolution
- Hardware decoding for real-time viewing
- 6× SATA HDD (up to 20TB each)
- M.2 SSD 256GB (pre-installed)
- Dual display: HDMI + DP ports
- 4× 2.5GbE RJ-45 ports
- USB 2.0, USB 3.0, audio, RS232/RS485
- Load balancing and N+M failover support
- Pre-installed Milesight VMS Enterprise
✨ Specifications Summary
Video & Decoding
- Channels: 16
- Video Formats: MJPEG, H.264, H.265
- Resolution: Up to 12MP
- Decoding (on 1080P monitor):
• D1@30fps = 16ch
• 2MP@30fps = 16ch
• 5MP@30fps = 11ch
• 12MP@20fps = 5ch
Storage
- 6× SATA HDD (3.5"/2.5"), up to 20TB each
- 1× M.2 SSD 256GB for OS
Display
- HDMI ×1, DP ×1
- Independent/synchronous display
Network
- 4× 2.5GbE RJ-45
- Client Connections: 300
- Users: 1000
- Roles: 100
Interfaces
- USB: 2× front USB 2.0, 2× rear USB 2.0, 2× USB 3.0
- Audio: HD Audio in/out
- PCIe Slot: 1× PCI-E 4.0 (Integrated GPU)
System
- CPU: Intel Celeron 2.0GHz
- RAM: 2× 4GB DDR4 SO-DIMM (expandable to 16GB)
- OS: Windows 10 IoT Enterprise
Power & Environmental
- Power: AC 100–240V, 50–60Hz
- Power Consumption: ≤30W (without HDD)
- Dimensions: 440mm × 420mm × 88.2mm
- Weight: 8.1kg
- Temperature: 0°C to 35°C
- Humidity: 10–90% RH
- Warranty: 3 Years
