Dahua OEM IPC-HDB4300F-PT 3MP Mini PT Dome IP Camera

  • Dahua OEM IPC-HDB4300F-PT 3MP Pan/Tilt Vandal Dome IP Camera
  • Dahua OEM IPC-HDB4300F-PT Pan/Tilt Dome Dimensions
Calculated at checkout

Product Description

Dahua OEM IPC-HDB4300F-PT 3MP Mini PT Dome IP Camera is a compact yet flexible IP dome security camera. The unit features a 3 Megapixel Image Sensor, delivers high frame rate video plus on-demand pan/tilt movement making it great for active surveillance demands. The unit employs dual streaming including H.264 compression and supports your stand-alone IP surveillance needs with a built-in memory card slot. The device further includes benefits like an integrated Microphone for comprehensive awareness. The unit performs well in low light, but we recommend it for areas with adequate lighting. Otherwise this unit is built tough and is suitable for indoor or outdoor environments and of course has ONVIF integration as well as PoE support all covered.

Dahua OEM IPC-HDB4300F-PT Main Features:

  • 1/3” 3 Megapixel progressive scan CMOS
  • H.264 & MJPEG dual-streaming
  • Up to 20fps at 3MP (2048×1536), Up to Real-time 30fps at 1080P (1920 x 1080)
  • Day/Night (Electronic), 3DNR, AWB, AGC, BLC and other image settings
  • Remote View: Web Interface, CMS (DSS/PSS) Client/NVR and DMSS Mobile Applications
  • Flexible Protocol Support: HTTPS, SSL, UPnP, RTSP, PPPOE, DDNS, FTP, QoS, ONVIF and more
  • 100°/s preset speed, ±180° Pan Range, 90°Tilt range
  • 3.6mm fixed lens w/HFOV: 72.5°
  • Built-in Microphone w/G.711a, G.711u or PCM Audio Codecs
  • Micro SD Card Slot for local video storage (64GB Maximum)
  • Weatherproof IP66 and vandal proof, high impact IK10
  • Operating Temperature: -30°C~+60°C, Less than 95% RH
  • Dimensions: Φ130mm x 57.5mm or Φ5.11" x 2.26"
  • Weight: 0.25kg or 0.55 lbs.
  • Power: 12VDC or PoE (802.3af)

Great Imaging:
The IPC-HDB4300F-PT Pan/Tilt 3MP Mini Vandal Dome IP Camera delivers some excellent video quality, it’s equipped with the same image sensor, plus enhancements found in similar Dahua 3MP models. It provides the In-depth image adjustments, a 72.5 degree horizontal viewing angle, 3D Noise Reduction (3DNR), Digital WDR (DWDR) plus Highlight Compensation (HLC) settings yielding some overall solid performance. One note is that it however uses Electronic Day/Night and has no IR night vision, so lighting must be considered for best results.

Innovative Design:
Employing the same base qualities as some of the most popular Dahua 3MP OEM IP Cameras these units serve a great purpose in key areas of actively used surveillance systems. This rather unique, mini vandal-proof dome IP camera provides a wealth of professional attributes that meld well with its affordable cost and specialized abilities. The primary specialty is its Pan/Tilt or "PT" ability allowing automated or on-demand pan and tilt movement. This combined with functions like a built-in microphone to on-board SD card recording all in a rugged case at this low cost is impressive. Users and administrators will appreciate great applications, diverse security settings to an array of IT protocols enabling sophisticated system compatibility.

Designed Smart, Built Tough:
This compact Dahua OEM PT 3MP Vandal Dome IP Camera is a great selection for a wide range of applications, home security, business, retail, you name it. As either its own IP Camera System with built-in detection, recording, viewing, playback and export via web interface this unit also make a great addition to other full scale system solutions. The device is IK10 high impact and IP66 weatherproof rated making it suitable for almost any environment. 12VDC or PoE installation plus with optional mounting accessories its can meet a wide range of security system applications that you might not expect.

NOTICE: For Dahua A2Z Sales primarily OEM product versions which means no brand labels and models may vary but all specifications are otherwise the same as referenced model.

Last Updated January 13, 2016
