Description
The A2Z AZMBFE-1L81D redefines ultra mini HD CCTV surveillance with its 8.4MP resolution powered by a 1/2.8” Sony STARVIS CMOS sensor and EYENIX EN781 image processor. It delivers up to 3840 x 2160 pixels (4K) UHD video at 15fps with switchable downscale modes to 1440P, 1080P or Analog CCTV (CVBS) for compatibility with lower resolution video systems.
This model supports a full suite of analog and digital video formats including AHD, TVI, CVI, CVBS, plus special order versions supporting alternatively EX-SDI, HD-SDI and CVBS. Despite its miniature size, the AZMBFE-1L81D offers rich image function enhancements like D-WDR, Defog, Shading, and 24-zone motion detection. The built-in OSD menu allows complete customization and seamless real-world adaptability.
Packaged in a solid, compact metal housing, it’s ideal for high-traffic areas requiring discreet, ultra-high resolution capture, such as financial terminals, healthcare settings, and transportation hubs.
Key Features:
- 8MP 4K UHD @ 15fp
- 1/2.8” Sony STARVIS CMOS Sensor (IMX515)
- Downscale Output: 1440P / 1080P
- Multi-Format: AHD, TVI, CVI, CVBS
- EX-SDI and HD-SDI versions optional
- Fixed 3.6mm Lens (Pinhole Lens Options)
- Digital Day/Night, Low Light: 0.012 Lux B&W
- D-WDR, Defog, Motion Detection
- Privacy Masking & Shading Controls
- Full Metal Body
- NDAA and TAA Compliant
- Made in Korea
Specifications Summary
- Video & Display
Sensor: 1/2.8” Sony CMOS, 8.40MP
ISP: EYENIX EN781
Max Resolution: 3840 x 2160 @ 15fps (4K UHD)
Output: AHD / TVI / CVI / CVBS (optional EX-SDI & HD-SDI)
Downscale: 1440P / 1080P
Min. Illumination: 0.12 Lux (Color), 0.012 Lux (B&W)
- Recording & Playback
Motion Detection: 24-Mask
Shutter: 1/30 ~ 1/30,000 (NTSC) / 1/25 ~ 1/25,000 (PAL)
DNR, WDR, Defog, Shading, Mirror, Flip: All Supported
OSD: Built-in
- Audio
N/A
- System / Security
Privacy Masking: On
Languages: English, Korean, Japanese, Chinese
- Interface & Ports
Coaxial Communication: Pelco-C / Hikvision-C / HD-CVI
- Power, Environmental, Mechanical
Power: DC12V ±10%
Consumption: 180mA
Temp: -10°C ~ +50°C
Dimensions: 121.56 x 67 x 65 mm (with mini mount)
Weight: 0.2kg
