Description
Designed for mid-sized enterprise and commercial security systems, the Milesight MS-N5016-NE delivers NDAA-compliant 4K surveillance recording across 16 IP camera channels. Supporting H.265+/H.264+ compression, it optimizes bandwidth and reduces video storage by up to 70%. The dual HDMI and VGA monitor interface allows simultaneous multi-display support and up to 4K resolution (HDMI).
Milesight's 5000 series Network Video Recorders support HTML5 plug-in free web browser operation and Milesight CMS PC Software to Milesight M-Sight Pro Mobile Applications for comprehensive remote video system management options. Multiples of units per site and/or multiple sites can all be managed efficiently with competitively priced, Linux embedded NVR appliances that are ultra reliable and hassle free. From small sites to enterprise level deployments using multiple units the MS-N5016-NE can enable next generation IP video surveillance with ease.
This unit includes 2 SATA ports supporting up to 20TB total storage and RAID 0/1 configuration for redundancy or performance. It offers seamless integration with Milesight Smart VCA event triggers, ANR edge recording, and supports ONVIF Profiles S, G, and T for cross-platform compatibility.
✨ Key Features
- 16CH 4K IP input with H.265+/H.264+ support
- NDAA-compliant manufacturing
- Dual Monitor HDMI port (4K capable) and VGA Port
- Up to 160Mbps bandwidth
- RAID 0/1 supported via dual SATA (20TB max)
- HTML5 H.265 Streaming
- AI VCA & LPR Management
- Smart VCA playback support
- ONVIF Profiles S/G/T
- USB 3.0/2.0, RS485, and alarm I/O support
- Embedded Linux system
- Metal housing with efficient ventilation
✨Specifications Summary
System
- OS: Embedded Linux
- Input: 16CH IP cameras
- Codec: H.265+/H.264+
- VCA: Milesight Smart VCA support
Video & Display
- Outputs: 1× HDMI (up to 3840×2160) 1x SVGA
- Display Layout: 1/4/8/9/16 split view
Recording & Playback
- Modes: Manual, Schedule, Event
- Simultaneous Playback: 16CH
- RAID: 0/1
Storage
- HDD Bays: 2× SATA (up to 20TB total)
- ANR Support: Yes
- Backup: Via USB/NAS/FTP
Network & Protocols
- LAN: 1× RJ45 (10/100/1000Mbps)
- ONVIF: S, G, T
- Protocols: TCP/IP, HTTP, HTTPS, DDNS, FTP, NTP, P2P, etc.
Audio
- Compression: G.711/AAC/G.722/G.726
Interface & Ports
- USB: 1× USB 3.0, 1× USB 2.0
- Alarm: 4 In / 1 Out
- RS485: 1 port
Mechanical
- Dimensions: ~300mm × 248mm × 50mm
- Weight: ~2.8kg
- Enclosure: All-metal
Power & Environmental
- Power Input: DC 12V, 4A
- Temp Range: -10°C to +55°C
- Humidity: 10%–90% non-condensing
