Description
The Milesight MS-N5008-PE brings NDAA-compliant 4K surveillance into one compact, power-efficient solution with integrated PoE capability. Supporting 8 IP channels and H.265+ compression, it offers top-tier performance while saving bandwidth, storage and cost.
Its built-in 8-port PoE switch streamlines installation, providing power and data over a single cable per camera without the need for additional equipment (i.e. external network PoE switch). HDMI output up to 4K resolution and VCA support makes it ideal for retail, education, and government environments with vary demands. The device as example can support advanced LPR (license plate recognition) management when paired with Milesight LPR IP Cameras.
This fanless, compact NVR supports ANR for backup footage and allows up to 10TB storage on a single internal SATA drive. The embedded Linux system ensures robust stability with a simplified, HTML5 plug-in free web browser-accessible GUI. Also included is access to Milesight's CMS PC Software and Mobile Applications ensuring feature rich remote system management that is both convenient and flexible.
✨ Key Features
- 8CH IP input with built-in 8-port PoE switch
- H.265+/H.264+ codec support
- NDAA-compliant hardware
- HDMI 4K output (3840×2160)
- 80Mbps bandwidth capacity
- HTML5 H.265 Streaming
- AI LPR Management
- Smart VCA and ANR support
- 1 SATA port up to 10TB HDD
- Dual USB ports (2.0/3.0)
- Compact fanless design
- Embedded Linux OS
✨Specifications Summary
System
- OS: Embedded Linux
- Channels: 8 IP cameras
- PoE Ports: 8× 10/100Mbps (IEEE 802.3af/at)
- Bandwidth: 80Mbps (in/out)
Video & Display
- HDMI Output: 1× 4K (3840×2160/30Hz)
- Split Display: 1/4/8
- VCA: Smart VCA event search/playback
Recording & Playback
- Recording Modes: Manual, Schedule, Event
- Playback Channels: 8 simultaneous
- Backup: USB device, FTP, NAS
Storage
- HDD: 1× SATA (up to 10TB)
- ANR Support: Yes
Network & Protocols
- LAN: 1× RJ45 10/100/1000Mbps
- ONVIF: Profiles S/G/T
- Protocols: TCP/IP, HTTPS, FTP, NTP
Audio
- Codec: G.711/AAC/G.722/G.726
Interface & Ports
- USB: 1× USB 3.0, 1× USB 2.0
- Alarm I/O: 4 in / 1 out
Mechanical
- Dimensions: ~300mm × 248mm × 50mm
- Weight: ~2.6kg
- Housing: Metal
Power & Environmental
- Power: 120W max with PoE
- Temp: -10°C ~ +55°C
- Humidity: 10–90% RH
