Description
Milesight’s MS-N1008-UC is an ultra-compact 8-channel 4K network video recorder built to deliver high-quality video recording in a sleek footprint. Equipped with an HDMI output supporting up to 3840×2160 resolution and H.265+/H.265 compression, this unit offers exceptional video quality and efficiency. Further from A.I. video processing when paired with Milesight AI IP Cameras to flexible remote viewing via CMS PC Software, Mobile Applications and HTML5 web browser streaming, the device delivers cutting edge features at a competitive cost.
Engineered for mid-sized systems, the NVR handles up to 80 Mbps bandwidth and supports dual-stream recording for bandwidth optimization. The Automatic Network Replenishment (ANR) feature ensures that if the network drops, camera-side storage takes over temporarily and syncs once the connection is restored. Numerous other professional advantages are likewise on-board from UHD local display to intelligent search functions and more!
With intuitive browser-based and client-side interfaces, compatibility with ONVIF-compliant devices, and smart search/playback tools, the MS-N1008-UC is perfect for commercial spaces needing reliable yet discreet surveillance infrastructure.
✨ Key Features
- 8-channel 4K IP camera input
- 80 Mbps incoming & outgoing bandwidth
- Dual HDMI video outputs for display flexibility
- HTML5 H.265 Streaming
- AI VCA Management
- H.265+/H.265/H.264+/H.264 support
- 4K UHD resolution (3840×2160) output
- 1x SATA interface supporting up to 10TB
- 2 USB 2.0 interfaces for export/backup
- Smart playback with motion detection search
- Compact 220mm × 200mm × 43.6mm housing
- Embedded Linux OS and ONVIF compatibility
- Optional 4 Port PoE Enabled Version MS-N1008-UPC Also Available
✨ Specifications Summary
System
- OS: Embedded Linux
- Input: 8-CH IP Camera
- Compression: H.265+/H.265/ H.264+/H.264
- Bandwidth: 80Mbps (in/out)
Video & Display
- Output: 1x HDMI up to 3840×2160
- Display Split: 1/4/8
- OSD Overlay: Camera Name, Motion Detection
Recording & Playback
- Modes: Manual/Scheduled/Event
- Playback: 8-CH simultaneous
- Backup: USB device, Network
Storage
- HDD: 1× SATA up to 10TB
- ANR: Supported
- File Format: .avi proprietary
Network & Protocols
- LAN: 1× RJ45 10/100Mbps
- Protocols: TCP/IP, DHCP, PPPoE, NTP, etc.
- ONVIF: Profiles S, G, T
Audio
- Formats: G.711, AAC, G.722, G.726
Interface & Ports
- USB: 2× USB 2.0
- Audio In/Out: None
- Alarm I/O: N/A
Mechanical
- Size: 220mm × 200mm × 43.6mm
- Weight: 0.95kg
- Material: Metal
Power & Environmental
- Input: DC 12V 2A
- Power: <10W
- Temp: -10°C ~ +55°C
- Humidity: 10–90%
