Description
The Hanwha WRR-P-S204x series represents a versatile, high-performance 2U rackmount video surveillance server preloaded with the powerful Wisenet WAVE Video Management System (VMS). Designed for scalability, reliability, and performance, this server family offers multiple operating system options to suit different enterprise needs: Ubuntu 22.04 (WRR-P-S204L), Windows Server 2022 (WRR-P-S204S), and Windows 11 IoT LTSC 2024 (WRR-P-S204W).
Each model supports up to 256 IP camera channels and delivers a substantial 1200 Mbps of recording throughput, making it ideal for mid-to-large-scale enterprise level deployments. With up to 240TB of raw, video-optimized 24/7 SAS storage capacity, users can select from a wide range of high-capacity configurations to meet long-term retention requirements. The systems are equipped with 12 front hot-swappable bays for flexible HDD setup and RAID configurations (RAID 0, 1, 5, 6, and 10) to ensure maximum uptime and data security.
These servers feature Intel® Xeon® processors, 16GB DDR4 memory, and include dual RAID 1 SSDs for the operating system and application environment—allowing for fast boot and recovery. Each unit comes standard with four WAVE Professional licenses, and customers can easily expand channel capacity by adding additional WAVE licenses.
The WRR-P-S204x lineup is ideal for customers seeking robust WAVE-based NVR performance in an all-in-one platform, with flexible OS support and long-term expandability. The device is a powerful hardware platform while Hanwha VMS WAVE software is an equally powerful IP video security solution harnessing vast advanced features. Licenses can be added in numerous capacities, over-time as needed and include life-time software upgrades. Boasting adaptable connectivity options including Mobile to Desktop Software interfaces with enhanced capabilities like A.I. metadata processing and forensic search, the solution ensure premium grade backbone to any large scale surveillance demand.
✨ Key Features:
- 2U rackmount server with Ubuntu, Windows IoT, or Windows Server OS
- Preloaded with Wisenet WAVE VMS, includes 4 x WAVE Professional licenses
- Supports up to 256 IP camera channels (expandable via WAVE licenses)
- Up to 240TB of 24/7 duty cycle SAS storage
- Dual RAID 1 SSDs for OS/application drives (2 x 480GB)
- RAID 0/1/5/6/10 configurations supported
- 1200 Mbps recording throughput
- 4 x RJ45 GbE standard, optional 10GbE SFP+ interfaces
- IPMI management, sliding rack rails, USB keyboard & mouse included
- 5-year, Next Business Day, Keep Your Hard Drive Warranty
⚖️ Specifications Summary:
Video & Display:
- Video Output: None specified
- Recording Throughput: Up to 1200 Mbps
- Max Channels: 256 (WAVE VMS licensed)
Recording & Playback:
- Recording Software: WAVE VMS
- Included Licenses: 4 x WAVE Pro (expandable)
- OS Drive: 2 x 480GB SSD RAID 1
- Recording Drive Bays: 12 x 3.5” hot-swap (up to 240TB)
Storage:
- RAID Support: 0, 1, 5, 6, 10
- Drive Type: SAS 24/7 video-optimized
- Max Storage: 240TB raw capacity
Network & Protocols:
- Default: 4 x RJ45 GbE
- Optional: 2 x RJ45 + 2 x 10GbE SFP+
- Remote Management: IPMI
Audio:
- Audio Input/Output: Not specified
System / Security:
- Operating Systems: Ubuntu 22.04 (L), Windows Server 2022 (S), Windows 11 IoT LTSC 2024 (W)
- Processor: Intel® Xeon®
- Memory: 16GB DDR4
Interface & Ports:
- USB: 2 x USB 2.0, 1 x USB 3.0
- Serial Ports: 1
- Included Accessories: Sliding rail kit, USB mouse & keyboard
Power, Environmental, Mechanical:
- Power Supply: 2 x 800W 80 Plus Platinum
- Operating Temp: 50°F–95°F (10°C–35°C)
- Storage Temp: -40°F–149°F (-40°C–65°C)
- Humidity: 5%–95% RH
- Dimensions: 18.97” x 30.39” x 3.41”
- Weight: 53.3 lbs (without HDDs)
- Heat Dissipation: 3000 BTU/hr
Model Options / Variants:
- WRR-P-S204L (Ubuntu 22.04)
- WRR-P-S204S (Windows Server 2022)
- WRR-P-S204W (Windows 11 IoT Enterprise LTSC 2024)
Compatible Accessories / Software:
- Additional WAVE VMS Licenses
- Optional 10GbE Network Interfaces
- Hot-swappable HDDs from 48TB up to 240TB (RAID-configurable)
