Description
The A2Z AZMBFE-1G81D is a 4MP mini bullet-style security camera built for compact, yet high-performance HD CCTV surveillance applications. Featuring the 1/2.8” Sony STARVIS CMOS sensor (IMX335) and the EYENIX EN781 ISP, it outputs crisp 2560 x 1440 (2K) resolution video with wide dynamic range and low-light sensitivity as low as 0.015 Lux.
Its Video output versatility covers AHD, TVI, CVI, and CVBS as standard formats, with EX-SDI or HD-SDI available in special version models. The AHD, TVI, CVI, CVBS signal support make it ideal for both legacy and modern video security systems. A 3.6mm fixed board lens provides broad field coverage, while advanced processing enables WDR, Defog, Privacy Masking, Motion Detection, and more.
Measuring just 36mm x 36mm in an aluminum die-cast housing, the AZMBFE-1G81D is discreet, durable, and perfect for tight installations, ATMs, POS stations, smart kiosks and plenty more.
Key Features:
- 4MP QHD 1440p @ 30fps
- 1/2.8” Sony STARVIS CMOS Sensor (IMX335)
- Multi-Format Output (AHD, TVI, CVI, CVBS)
- Optional SDI versions (EX-SDI, HD-SDI)
- Fixed 3.6mm Lens (pinhole lens options)
- Day/Night, Ultra Low Light Performance
- Digital WDR, Defog, Motion Detection
- Privacy Masking with 24 Zones
- Compact Miniature Metal Body (18.8mm diameter)
- Built-in OSD & Configurable Functions
- NDAA and TAA Compliant
- Made in Korea
Specifications Summary
- Video & Display
Sensor: 1/2.8” 5.14MP Sony CMOS
ISP: EYENIX EN781
Resolutions: 1MP / 2MP / 4MP
Max Output: 2560 x 1440 @ 30fps
Video Output: AHD / TVI / CVI / CVBS / EX-SDI
Min. Illumination: 0.15 Lux (Color), 0.015 Lux (B&W)
- Recording & Playback
Motion Detection: 24-Mask (16 box / 8 polygon)
Shutter Speed: 1/30 ~ 1/30,000 (NTSC), 1/25 ~ 1/25,000 (PAL)
DNR, Defog, WDR: Supported
OSD: Built-in
- Audio
N/A
- System / Security
Privacy Masking: On (24 Mask Zones)
Languages: EN, KR, JP, CN
- Interface & Ports
Coaxial Control: AHD: Pelco-C, TVI: Hikvision-C, CVI: HD-CVI
- Power, Environmental, Mechanical
Power: DC12V ±10%
Consumption: 150mA
Operating Temp: -10°C ~ +50°C
Dimensions: 121.56 x 67 x 65 mm (with mini mount)
Weight: 0.2kg
