Bosch

Bosch VBC-4075-C21 AN 4000 Color Box Security Camera 960H

Write a Review
SKU:
VBC-4075-C21
  • Bosch VBC-4075-C21 AN 4000 Color Box 960H
  • Bosch VBC-4075-C21 AN 4000 Menu On-Screen Display Control
  • Bosch VBC-4075-C21 AN 4000 Menu OSD Control Instructions
Contact Us for Replacements

Description

NOTICE: This product has been discontinued or is EOL and therefore in most cases no longer available - Please contact our Experts or search the category link below or other related categories.

https://www.a2zsecuritycameras.com/cctv-security-cameras.html



Bosch VBC-4075-C21 AN 4000 Color Box Security Camera is a premium resolution 960H CCTV surveillance camera. The unit includes the upgraded 960H Image Sensor for 720TVL High Resolution image capture. Additionally a variety of enhanced image processing technologies for optimized video surveillance achieve maximum clarity in harsh lighting conditions. The unit offers digital day/night with great low light viewing, however a True ICR model is available. The cost saving, high performance unit challenges the market with a best in class model of prestigious quality and effectiveness.

Advanced image processing includes attributes like Digital Noise Reduction (2DNR), High Light Compensation (HLC) and Digital Dynamic Range for superb image reproduction even in the harshest lighting. The OSD (on-screen display) with external menu controls also provides easy CCTV camera settings including in-depth video image configurations to privacy masking or motion detection. All around high grade video security is achieved in projects with limited and tough lighting conditions.

Bosch VBC-4075-C21 AN 4000 CCTV Box Security Camera is truly a professional surveillance unit allowing customized lens selection, dual voltage input and cable compensation. Support for indoor and outdoor mounting in a variety of styles support standard 1/4-20 mounting and housings for all your install needs. Contact A2Z's Experts today to learn more about the latest in 960H and over 700TVL video surveillance.

Bosch VBC-4075-C21 AN 4000 Main Features:

  • Premium high Resolution 960H (1/3“CCD) 720TVL
  • Minimum Illumination (F1.2, 30IRE) Color: 0.05 lux
  • Digital Day/Night Function
  • Digital Noise reduction 2DNR
  • Digital Extended Dynamic Range
  • White Balance, Light compensation OFF/BLC/HLC
  • VMD - Video Motion detection 4 configurable zones)
  • Privacy 8 configurable zones (4 zones w/VMD on)
  • Multiple Language OSD (On-Screen Display Menu)
  • Supports DC Iris Lenses and CS mount or C-mount Lens Types
  • Operating Temperature -20 °C to +55 °C (-4 ºF to +131 ºF)
  • Operating Humidity 20% to 90% RH
  • Dimensions (without lens) 58mm x 66mm x 122mm (2.28 x 2.6 x 4.8-inches)
  • Weight (12 VDC/24 VAC) 500 g (1.10 lbs) without lens
  • Weight (230 VAC) 600 g (1.32 lbs) without lens
  • Power Input (VBx-4075-C11, VBx-4075-C21) 12VDC / 24VAC
  • Power Input (VBx-4075-C51) 230 VAC PAL OPTION
  • Power Consumption (True D/N) 3.6 Watts max. / 0.3 Amp
  • 12VDC / 24VAC and 230V Power Input Models
  • Power Consumption: 2.4 Watts max. / 0.2 Amps

Ordering information
DINION AN 4000
True day/night; 12VDC/24VAC; PAL: Order number VBN-4075-C11
DINION AN 4000
True day/night; 12VDC/24VAC; NTSC: Order number VBN-4075-C21
DINION AN 4000
True day/night; 230VAC; PAL Order number VBN-4075-C51
DINION AN 4000
Electronic day/night; 12VDC/24VAC; PAL: Order number VBC-4075-C11
DINION AN 4000
Electronic day/night; 12VDC/24VAC; NTSC: Order number VBC-4075-C21
DINION AN 4000
Electronic day/night; 230VAC; PAL: Order number VBC-4075-C51
