A2Z PTZ-59NVIR36S 36x Infrared (IR) PTZ Dome Security Camera

  • A2Z PTZ-59NVIR36S 36x Infrared (IR) PTZ Dome Security Camera
  • A2Z PTZ-59NVIR36S IR PTZ Camera Dimensions Diagram
Calculated at checkout

Product Description

A2Z Security Cameras PTZ-59NVIR36S IR PTZ Dome Security Camera introduces a new standard in highly versatile and high performance CCTV Surveillance. The PTZ-59NVIR36S Infrared PTZ Cameras deliver 540TVL high resolution imaging combined with powerful 36x optical zoom and precision high speed movement. The unit includes True Day/Night operation and WDR (Wide Dynamic Range) for superb video quality in all lighting. In addition, integrated Infrared LED illumination with Auto Adjusting IR Intensity likewise ensures clear video surveillance even in zero light environments. The Infrared Illumination is capable of distances to 590 Feet (180 meters) for incredible night vision and thus anytime video security.

The A2Z PTZ-59NVIR36S IR PTZ Dome Camera is feature packed with superior Pan/Tilt/Zoom operation and includes a wide range of automated PTZ functions. The unit also includes additional benefits such as I/O input, Privacy Masking and complete camera configuration via OSD menu. The Infrared PTZ Dome Camera is weatherproof outdoor ready and is available with a variety of mounting options for all types of installation needs. The unit is perfect for active surveillance in many styles of security camera systems with exceptional cost effectiveness, performance and reliability.

A2Z PTZ-59NVIR36S Main  Features :

  • 540TVL High Resolution
  • 6" Outdoor Speed Dome PTZ camera
  • 432X Total Zoom (36X Optical , 12X Digital)
  • Integrated Infrared LED Array with Auto Adjustment for Zoom (180m / 590ft IR Distance)
  • 360 degree horizontal rotation at maximum speed of 360 degree /sec
  • 360°continuous pan and 350° auto-flip tilt rotation
  • PTZ Dome functions Presets, Auto Scans, Patterns, Tours
  • 220 preset positions, 4 Patterns, 8 Auto Scans, 8 Cruise Groups
  • Password protected PTZ Dome Camera settings
  • Multiple protocol Support with RS485 PTZ Telemetry Control
  • IP65 Weatherproof Rating
  • 12VDC Power Input

A2Z PTZ-59NVIR36S Specifications:

Picture Elements: Approx., 380K Pixels (NTSC) / Approx., 440K Pixels (PAL)
Horizontal Resolution: NTSC: 540TVL (wide end) / PAL: 540TVL (wide end)
Motorized Zoom Lens: 36x Optical f=3.4mm(WIDE)-122.4 mm(TELE) F1.6 to F4.5
Zoom Speed Movement (NTSC):
Optical Wide/Optical Tele 4.0sec
Optical Wide/Digital Tele 6.0sec
Digital Wide/Digital Tele 2.1sec
Focus Movement Time: Far to Near 1.0sec
Digital Zoom: 12x (432x with optical zoom)
Angle of View: Approx. 57.8° (wide end) to Approx. 1.7°(Tele end)
Min. Working Distance: 320mm (Wide end),1500mm (Tele end)
Sync System: Internal / External (V-Lock)
Min. Illumination:
1.4 1x (F1.4, 1/60 s (NTSC) or 1/50s (PAL)
0.1 1x (F1.4, 1/4 s (NTSC) or 1/3s (PAL))
ICR ON (B/W Mode) : 0.01Lux 1/4sec (NTSC), 1/3 sec (PAL)
Infrared ON (B/W Mode) : 0 Lux (True Night Vision)
S/N Ratio: 50dB (Weight ON
Back Light Compensation: ON/OFF
Electronic Shutter Speed: NTSC: 1/4 to 1/10000 sec. (20 steps)
PAL: 1/3 to 1/10000 sec. (20 steps)
White Balance: : AUTO, ATW, Indoor, Outdoor, One Push WB, Manual WB
Gain: Auto / Manual (-3 to 28dB, 16steps)
Aperture Control: 16 Steps
Video Output: VBS: 1.0Vp-p (Sync negative), Y/C Output
WDR (Wide Dynamic Range): ON/OFF
Pan Rotation: 360°
Tilt Rotation: 90° Tilt with Auto Flip
Pan Preset Speed: 0~ 360°/s
Tilt Preset Speed: 0 ~ 120°/s
Alarm Function: 2 Inputs / 1 Outputs
Presets: 220
Surveillance modes: 8 cruise groups, 32 presets per group
8 Auto Scan groups
4 Patterns groups, 500 movements per group
Speeds: Magnification Proportional Pan
Baud rate: 2400/4800/9600/19200bps
Communication: RS485 Interface
Address Range:1-255
Auto Home: On/Off (resume tours or preset)
Power Resume: On/Off (resume commands after power loss)
Privacy Masking: 8 Zones on/off
OSD Menu: Enabled
Temperature Control: Control Fan Activation by OSD Menu
IR Control: PTZ System Automatically adjust the IR by zoom magnification or Motion
IR Illumination Range: 180 Meter / 590 Feet
Weight 3.2Kg / 6.4 lbs.
Operational Temperature: Outdoor: -35°C ~ +55°C
Relative Humidity: 90% without agglomeration
IP Grade: IP65
Power Consumption:  36W
