Everfocus EMV800 8 channel Mobile DVR D1 240fps

  • Everfocus EMV800 8 channel Linux Mobile DVR System (shown with WiFi)
  • Everfocus EMV800 8ch Mobile DVR side view (shown with WiFi)
  • Everfocus EMV800 8ch Mobile DVR Diagram
  • Everfocus EMV800 DVR Specifications
  • Everfocus EMV800 8 channel Mobile DVR
Contact us for Pricing

Product Description

Everfocus EMV800 8 channel Mobile DVR solution is a solid choice for all types of CCTV video surveillance in transportation and transit applications. The unit enable 120fps at high resolution D1 video recording including optimized H.264 video compression. The Mobile DVR is built entirely for rugged applications and includes best in class features and a top choice among any Mobile Linux DVR system. Superior local hardware to well-developed software interface the solution offers video security and surveillance that is of true professional grade.

Intelligent design includes all the common functions of a modern Digital Video Recorder such as Two Way Audio, I/O Communications and RS-485 PTZ Camera Control. Even DVR System PTZ Joystick keyboard Everfocus controllers are supported. The unit allows full function video security from the local level including main and spot monitor output as well as front panel controls, USB mouse and IR remote control support. The Mobile DVR further incorporates flexible power input ranging 12-36VDC, embedded G-sensor and even optional Wireless such as WiFi with model EMV800W. Rugged construction and mounting configuration ensure an anti-shock and anti-vibration design for maximum reliability.

Powerful DVR Software includes optimized local viewing display, remote viewing via applications like CMS and even mobile viewing with smart phones or tablets. Enhanced functionality is delivered in viewing, search, playback, export and networking. Fully capable DVR software allows event triggers and event actions like email notification or FTP uploads. Add-ons like GPS modules allow real-time tracking and mapping of DVR units and overall the Everfocus EMV800 is a top of the line choice.

Everfocus EMV800 Main Features:

  • Rugged Linux Embedded Mobile DVR (Anti-Vibration/Shock)
  • 8 Channel Video Inputs
  • D1/4CIF Resolution Real-time at 240fps
  • H.264 Compression w/Dual Streams for optimized file size and network transmission
  • 8 Channel Audio input and 1 Audio output
  • Supports Removable Hot Swap Hard Drive Bay (1TB max size)
  • Optional Wireless WIFI MODEL: EMV800W
  • Intelligent DVR Software for professional local and remote video management
  • 10 User Security Profile Levels with specific rules
  • Local Operation with Front Panel, IR Remote or DVR Keyboard Joystick or USB Mouse
  • BNC or RCA Main Monitor and Call Monitor
  • Free Mobile viewing with Everfocus MobileFocus Application: Supports iPhone, Android and Blackberry
  • FREE DDNS Service Hosted by Everfocus for simple Remote Access without Static IP
  • Advanced Detection, Event Triggers and Event Notifications to Digital Zoom on Live Video or Playback
  • Optional GPS sensor supports Tracking including speed and geographical rules
  • Embedded 3-axis G Sensor: data recorded and alarm (user configurable)
  • Optional External EDGE/GPRS/DCMA/WiFi modules for cellular and other wireless transmission
  • Embedded 3-axis G-sensor support alarm function and user configurations
  • Supports single 2.5” SATA hard disk (up to 500 GB)
  • Multiple interfaces: 3 x USB, RS-485, RS-232, GPS port, wired Ethernet, IR Remote Control
  • Includes Specialized Mounting Bracket with Anti-Vibration and Anti-Shock Design
  • Features Anti-Vibration resistant Molex Locking Cabling Connections
  • Optional: Wireless 802.11 b/g with diversity antennas (WIRELESS MODEL EMV800W)
  • Optional: External EDGE/GPRS/CDMA/WiFi Modules
  • Optional: GPS function (external GPS receiver)
  • Extended Operating Temperature (F | C) -40°F~131°F | -40°C~55°C
  • Power Source 10VDC-32VDC input

EMV800/500: 8 Channel Mobile DVR with 500GB
EMV800W/500: 8 Channel Wi-Fi Mobile DVR with 500GB
