Dahua OEM NVR4104H-P Network Video Recorder 4ch 4 PoE

  • Dahua OEM NVR4104H-P Linux NVR 4 channel 4 PoE
  • Dahua DMSS Mobile Viewing Apps
  • Dahua NVR4104H-P Linux NVR rear panel diagram
Calculated at checkout

Product Description

Dahua OEM NVR4104H-P 4ch Network Video Recorder introduces a new age of low cost, feature rich and fully professional Linux NVR systems. Cased in a sleek 1U small form factor design this dual core Linux Embedded NVR allows H.264 or MJPEG video stream recording at up to 5 Megapixel resolution from 4 IP Cameras. This Network Video Recorder further provides a built-in 4 Port PoE network switch simplifying the modern day IP Camera System even more. Integrated is also an amazing set of professional, high performing attributes despite the low cost. Local 1080P monitoring via HDMI or VGA, there is Two Way Audio Support, USB back-up and support for a single high capacity Surveillance HDD of your choice. Quickly integrate Dahua IP Cameras and even support 3rd party IP Cameras or use ONVIF comparability. Comprehensive surveillance system management is also achieved with this compact NVR. Like other Dahua IP products this video recorder supplies a full function web interface as well as CMS software to mobile applications for devices like Android, iPad, iPhone and Windows Phones. This and much more make the Dahua OEM NVR4104H-P 4ch Network Video Recorder a very popular solution.

Dahua OEM NVR4104H-P Main Features:

  • Linux Embedded Network Video Recorder
  • 4 channel IP camera Support up to 5 Megapixel Streams
  • 4 Port PoE Switch Built-in
  • 80Mbps bandwidth throughput with H.264 or MJPEG dual codec decoding
  • HDMI/VGA simultaneous HD video output
  • All channel synchronous real-time playback, GRID interface
  • Full Function Web Interface plus PC or MAC supported VMS and CMS Software (DSS/SmartPSS)
  • DMSS Dahua Mobile Viewing Applications are also available for Windows, iPhone, iPad and Android devices
  • 3rd Party IP cameras: Dahua, Arecont, AXIS, Bosch, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and more
  • ONVIF Compliant plus IT functions like IPv4/IPv6, UPNP, RTSP, DNS, IP Filter, DDNS, FTP, Alarm Server
  • 3D intelligent positioning with Dahua PTZ camera
  • Supports 1 SATA HDD up to 4TB, 2x USB2.0
  • Support IPC UPnP, 4 PoE ports (IEEE802.3at/af Max 25.5 Watts per)
  • NVR Power: 48V 1.5 amp Power Supply Included
  • Power Consumption NVR: 10 Watts (without HDD)
  • Temperature Range: -10°C~+55°C / 10%~90RH / 86~106kpa
  • Dimension (W×D×H) Smart 1U, 205mm × 205mm × 45mm
  • Weight: 1.1lbs or 0.5KG (without HDD)

NOTICE: OEM products are original to referenced model except produced without brand labels for re-branding


Professional Network Video Recorder:
Dahua OEM NVR4104H-P 4ch Linux NVR system is compact, cost effective yet highly feature rich video management system. The device includes a wide set of powerful video security functions for live viewing, recording, search, playback and export operations. The support for multi-streaming, H.264 or MJPEG and up to 80Mbps throughput provides flexible, powerful video recording of up to 5 Megapixel IP cameras multiplied by four. Added features beyond the display include USB ports for control and Back-up. There is a Two Way Audio interface for Microphone and Speaker. A built-in 4 Port PoE 802.3af and 802.3at compliant network switch is another innovative and most beneficial hardware attribute.

Superb Local and Remote Viewing:
Locally USB mouse control to optional Network Keyboard Joystick Controller and HD Display via HDMI plus VGA provide an efficient, easy to use system on-site. Remotely things are even more diverse with a well-developed, easy to navigate, feature packed Web Browser Interface that also provides full system control. Beyond that there is included Remote Surveillance Software like the SmartPSS CMS enabling multi-site, multi-device management and it is supported by both MAC and PC computers. Mobile Viewing is likewise generously delivered with one of the industry's best mobile surveillance apps for Windows Phone, iPhone, iPad and Android devices.

Last Updated May 2nd, 2016
